Part#:8903LG71V02

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

Contactor, Type L, multipole lighting, electrically held, 30A, 8 pole, 600 V, 110/120 VAC 50/60 Hz coil, NEMA 1

Product Details

  • Depth
    6.02 in (153 mm)
  • Number Of Poles
    8P 7 NO + 1 NC
  • Electrical Connection
    Screw-clamp terminals
  • Product Or Component Type
    Electrically Held Lighting Contactor
  • Height
    12.68 in (322 mm)
  • Range Of Product
    8903L
  • Pilot Light
    No indicator
  • Control Unit
    No control units
  • Control Circuit
    Separate control circuit
  • Width
    7.80 in (198 mm)
  • Inrush Power In VA
    150 VA 60 Hz 140 VA 50 Hz
  • Hold-In Power Consumption In VA
    35 VA 60 Hz 35 VA 50 Hz
  • Control Circuit Voltage
    110 V AC 50 Hz 120 V AC 60 Hz
  • Current Rating
    20 A tungsten 30 A fluorescent

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
