9070T75D37 Schneider Electric Electronic Components

9070T75D37 on Powermatic Associates
Schneider Electric

Part#:9070T75D37

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

Transformer, Type T, industrial control, 75 VA, 600 VAC primary / 120/240 VAC secondary, 1 phase, 50/60 Hz, 55 °C rise

Product Details

  • Electrical Connection
    Screw clamp terminals
  • Product Type
    Industrial Control Transformer
  • Fingersafe Cover Compatibility
    FSC1
  • Number Of Phases
    1 phase
  • Type
    T
  • Depth
    3.34 in (84.84 mm)
  • Temperature Rise
    55 °C
  • Width
    3.38 in (85.85 mm)
  • Height
    2.89 in (73.41 mm)
  • Power Rating
    75 VA

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

9070T75D37 Related Documents

Instruction Sheet-1631036536049.pdfProduct Datasheet-1631036536042.pdfCatalog-1631036536057.pdf
