AP2320G4ST Schneider Electric Electronic Components

AP2320G4ST on Powermatic Associates
Schneider Electric

Part#:AP2320G4ST

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

BUSWAY PLUG-IN STRAIGHT LENGTH 4FT 2000A

Product Details

  • Integral Ground
    50 percent capacity integral ground bus
  • Line Rated Current
    2000 A
  • Busbar Material
    Aluminium busbar
  • Wiring Configuration
    3-wire
  • Range Of Product
    I-Line
  • Number Of Phases
    3 phase
  • Short Circuit Rating
    125 kA
  • Length
    4 ft (1.22 m)
  • Product Or Component Type
    Straight length
  • Rated Voltage
    600 V AC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of AP2320G4ST on Powermatic Associates is $7,927.58. Order now.
