ATV61HU40S6X Schneider Electric Variable Frequency Drives (VFD)

ATV61HU40S6X on Powermatic Associates
Schneider Electric

Part#:ATV61HU40S6X

Manufacturer:Schneider Electric

Category:Variable Frequency Drives (VFD)

Product Lifecycle:Active

Product description

Schneider Electric ATV61HU40S6X is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the Altivar 61 series designed with a built-in heatsink. It operates on a supply voltage of 425-660Vac, including nominal voltages of 440Vac, 480Vac, 500Vac, and 600Vac. This model features dimensions of H295mm x W210mm x D213mm and offers an IP20 UL type 1 degree of protection. It has a rated current of 7.5A at 500Vac and 4kHz, 6.1A at 575Vac and 4kHz, with a maximum current of 9A for 60 seconds. The ATV61HU40S6X supports wall mounting and uses Modbus and CANopen communication protocols. It is designed for a 3-phase network with an output frequency range of 0.1-599 Hz. The unit includes 1 analog output (0-10Vdc / 0-20mA), 5 digital inputs (24Vdc; sink/source) that are programmable, plus an additional programmable digital input and a PWR safety input. It also features 1 digital output with a changeover SPDT relay contact and another with a normally open relay contact. The analog inputs consist of one accepting -10...+10Vdc and another for 0-10Vdc / 0-20mA signals. The current consumption is rated at 12.5A for 500Vac and 10.9A for 600Vac, with a rated active power of 4kW and a rated power of 5HP.

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

Manufacturer warranty

ATV61HU40S6X Schneider Electric

Get a quick Quote!

Request a quote, and we will send you price and availability within minutes.

Select Qty:

Average response time: 11 minutes

Worldwide Shipping and Delivery

Secure Payment Processing

Warranty

Responsive Customer Support

Got Questions? We've Got Answers!

Need more details?

Feel free to chat with us

About the manufacturer

Schneider Electric

Powermatic Associates is an authorized Schneider Electric distributor, proudly offering a diverse portfolio of innovative solutions tailored to meet the dynamic needs of today's industrial landscape. Schneider Electric stands as a global leader in energy management and automation, providing cutting-edge products and services that drive efficiency and sustainability across a variety of sectors. The...
