CA2KN223B7 Schneider Electric Industrial Automation Components

CA2KN223B7 on Powermatic Associates
Schneider Electric

Part#:CA2KN223B7

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Schneider Electric CA2KN223B7 is a contactor with a mechanical durability of 10,000,000 operations at no load. It is designed for plate DIN rail mounting and falls under the utilisation categories AC-15 and DC-13. This model features two SPST-NO (Single Pole Single Throw - Normally Open) contacts and is equipped with spring-type terminals. It has an operating rate of up to 10,000 cycles per hour.

Product Details

  • Product Name
    TeSys CAK
  • [Ue] Rated Operational Voltage
    <= 690 V <= 400 Hz
  • Hold-In Power Consumption In VA
    4.5 VA 68 °F (20 °C))
  • Depth
    2.24 in (57 mm)
  • Non Overlap Distance
    0.02 in (0.5 mm)
  • [Ith] Conventional Free Air Thermal Current
    10 A 122 °F (50 °C)
  • Mechanical Durability
    10 Mcycles
  • Width
    1.77 in (45 mm)
  • Pole Contact Composition
    2 NO + 2 NC
  • Inrush Power In VA
    30 VA 68 °F (20 °C))
  • Contactor Application
    Control circuit
  • Control Circuit Type
    AC 50/60 Hz
  • Immunity To Microbreaks
    2 ms
  • Device Short Name
    CA2K
  • Maximum Operating Rate
    10000 cyc/h
  • Insulation Resistance
    > 10 MOhm
  • [Uc] Control Circuit Voltage
    24 V AC 50/60 Hz
  • Product Or Component Type
    Control relay
  • Minimum Switching Current
    5 mA
  • Height
    2.28 in (58 mm)
  • Range
    TeSys
  • Irms Rated Making Capacity
    110 A IEC 60947
  • Net Weight
    0.40 lb(US) (0.18 kg)
  • Heat Dissipation
    1.3 W
  • Minimum Switching Voltage
    17 V
  • Utilisation Category
    DC-13 AC-15
  • Connections - Terminals
    spring terminals 1 0.00…0.00 in² (0.75…1.5 mm²)solid spring terminals 1 0.00…0.00 in² (0.75…1.5 mm²)flexible without cable end
  • Mounting Support
    Plate Rail
  • Associated Fuse Rating
    10 A gG IEC 60947 10 A gG VDE 0660
  • Control Circuit Voltage Limits
    Drop-out 0.2...0.75 Uc 122 °F (50 °C)) Operational 0.8...1.15 Uc 122 °F (50 °C))
  • [Ui] Rated Insulation Voltage
    690 V IEC 60947 750 V VDE 0110 group C 690 V BS 5424 600 V CSA C22.2 No 14
  • Operating Time
    10...20 ms coil de-energisation and NO opening 10...20 ms coil energisation and NO closing 15...25 ms coil de-energisation and NC closing 5...15 ms coil energisation and NC opening

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of CA2KN223B7 on Powermatic Associates is $47.66. Order now.

CA2KN223B7 Related Documents

Product Datasheet-1631040086577.pdfCatalog-1631040086579.pdfInstruction Sheet-1631040086580.pdf
