Part#:CA4KN225BW3

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

Schneider Electric CA4KN225BW3 is a contactor designed for plate DIN rail mounting with a mechanical durability of 30,000,000 operations at no load. It features two SPST-NO (Single Pole Single Throw - Normally Open) contacts, spring type terminals, and is rated for an operating rate of 6,000 cycles/hour. This part falls under the utilisation categories AC-15 and DC-13, indicating its suitability for specific types of electrical loads.

Product Details

  • Control Circuit Type
    DC low consumption
  • Non Overlap Distance
    0.02 in (0.5 mm)
  • Minimum Switching Voltage
    17 V
  • Depth
    2.24 in (57 mm)
  • Product Name
    TeSys CAK
  • Coil Technology
    Built-in bidirectional peak limiting diode suppressor
  • Mechanical Durability
    30 Mcycles
  • Minimum Switching Current
    5 mA
  • [Ue] Rated Operational Voltage
    <= 690 V <= 400 Hz
  • Product Or Component Type
    Control relay
  • [Uc] Control Circuit Voltage
    24 V DC
  • Maximum Operating Rate
    6000 cyc/h
  • Width
    1.77 in (45 mm)
  • Pole Contact Composition
    2 NO + 2 NC
  • Connections - Terminals
    solder pins 1.5 x 0.9 mm
  • Height
    2.28 in (58 mm)
  • [Ith] Conventional Free Air Thermal Current
    10 A 122 °F (50 °C)
  • Immunity To Microbreaks
    2 ms
  • Insulation Resistance
    > 10 MOhm
  • Range
    TeSys
  • Device Short Name
    CA4K
  • Irms Rated Making Capacity
    110 A IEC 60947
  • Inrush Power In W
    1.8 W 68 °F (20 °C))
  • Net Weight
    0.58 lb(US) (0.265 kg)
  • Contactor Application
    Control circuit
  • Hold-In Power Consumption In W
    1.8 W 68 °F (20 °C)
  • Heat Dissipation
    1.8 W
  • Utilisation Category
    DC-13 AC-15
  • Control Circuit Voltage Limits
    Drop-out 0.1...0.75 Uc 122 °F (50 °C)) Operational 0.7...1.3 Uc 122 °F (50 °C))
  • Associated Fuse Rating
    10 A gG IEC 60947 10 A gG VDE 0660
  • Mounting Support
    Plate Rail
  • [Ui] Rated Insulation Voltage
    690 V IEC 60947 750 V VDE 0110 group C 690 V BS 5424 600 V CSA C22.2 No 14
  • Operating Time
    10...20 ms coil de-energisation and NO opening 15...25 ms coil de-energisation and NC closing 30...40 ms coil energisation and NO closing 25...35 ms coil energisation and NC opening

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
