CD325NR Schneider Electric Electronic Components

CD325NR on Powermatic Associates
Schneider Electric

Part#:CD325NR

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

Safety switch, general duty, fusible, 400A, 120/240 VAC, 3 poles, 125 hp, solid neutral, NEMA 3R

Product Details

  • [Ue] Rated Operational Voltage
    120/240 V AC
  • Number Of Poles
    3
  • Product Or Component Type
    Single Throw Safety Switch
  • Tightening Torque
    340 lbf.in (38.41 N.m) (AWG 1/0...250 kcmil)
  • Device Composition
    Neutral (factory installed)
  • AWG Gauge
    AWG 1/0...600 kcmil copper or aluminium
  • Device Mounting
    Surface
  • Width
    22.25 in (565.15 mm)
  • Disconnector Device Type
    Fusible disconnect
  • Depth
    10.13 in (257.30 mm)
  • Electrical Connection
    Lugs
  • Short-Circuit Current
    100 kA maximum cartridge
  • Height
    30.63 in (778.00 mm)
  • Series Name
    General duty
  • Maximum Horse Power Rating
    50 hp 240 V at AC 50-60 Hz for 3 phase conforming to NEC 240.6 125 hp 240 V at AC 50-60 Hz for 3 phase conforming to NEC 430.52

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of CD325NR on Powermatic Associates is $3,707.00. Order now.
