DTU462DS Schneider Electric Electronic Components

DTU462DS on Powermatic Associates
Schneider Electric

Part#:DTU462DS

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

SW NOT FUSIBLE DT 600V 60A 4P NEMA4 4X 5

Product Details

  • Width
    16.75 in (425.45 mm)
  • Factory Installed Neutral
    None
  • Mounting Type
    Surface
  • Current Rating
    60 A
  • Height
    30.26 in (768.60 mm)
  • Product
    Double Throw Safety Switch
  • Enclosure Rating
    NEMA 4/4X/5 stainless steel 304
  • Net Weight
    57.01 lb(US) (25.86 kg)
  • Number Of Poles
    4
  • Depth
    7.12 in (180.85 mm)
  • Disconnect Type
    Non-fusible disconnect switch
  • Duty Rating
    General duty
  • Voltage Rating
    600 V AC 600 V DC
  • Wire Size
    AWG 12...AWG 2 aluminium AWG 14...AWG 2 copper
  • Fuse Type
    H or K R, J or T
  • Short-Circuit Current
    10 kA H or K 100 kA R, J or T
  • Maximum Horse Power Rating
    20 hp 240 V at AC 50-60 Hz for 2 phases conforming to NEC 240.6 20 hp 240 V at AC 50-60 Hz for 3 phase conforming to NEC 430.52 40 hp 480 V at AC 50-60 Hz for 2 phases conforming to NEC 240.6 50 hp 480 V at AC 50-60 Hz for 3 phase conformin
  • Tightening Torque
    35 lbf.in (3.95 N.m) 0.00…0.01 in² (2.06…5.26 mm²) (AWG 14...AWG 10) 40 lbf.in (4.52 N.m) 0.01 in² (8.37 mm²) (AWG 8) 45 lbf.in (5.08 N.m) 0.02…0.03 in² (13.3…21.15 mm²) (AWG 6...AWG 4) 50 lbf.in (5.65 N.m) 0.04…0.05 in² (26.67…33.62 mm²) (

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of DTU462DS on Powermatic Associates is $10,024.50. Order now.

DTU462DS Related Documents

Product Datasheet-1631035457353.pdfCatalog-1631035457350.pdf
