Part#:H221N

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

240 VAC/250 VDC, 30 A, 500 HP, 3-Phase, 2-Pole, 3-Wire, Galvannealed Steel, Surface Mount, NEMA 1, Class R/J/H/K, Fusible, Factory Installed Neutral, Heavy Duty

Product Details

  • Phase
    3 phase
  • Mounting Type
    Surface
  • Wiring Configuration
    3-wire
  • Net Weight
    8.82 lb(US) (4 kg)
  • Device Application
    Heavy application
  • Duty Rating
    Heavy duty
  • Width
    6.5 in (165.10 mm)
  • Product
    Single Throw Safety Switch
  • Current Rating
    30 A
  • Electrical Connection
    Lugs
  • Number Of Poles
    2
  • Depth
    4.88 in (123.95 mm)
  • Height
    14.6 in (370.84 mm)
  • Enclosure Rating
    NEMA 1 steel
  • Disconnect Type
    Fusible disconnect
  • Factory Installed Neutral
    Neutral (factory installed)
  • UPC:
    785901477686
  • Number of Wires:
    3
  • Shipping Length:
    16.00 In.
  • Amps:
    30 A
  • Poles:
    2
  • Fuse Type:
    Class R/J/H/K
  • Enclosure:
    NEMA 1
  • Fuse Provision:
    Fusible
  • Shipping Weight:
    7.80
  • AC Voltage Rating:
    240 Volt
  • Shipping Width:
    8.00 In.
  • Power Rating:
    200 HP at 240 Volt AC 3-Phase
  • Size:
    6.5 Inch Width x 4.88 Inch Depth x 14.6 Inch Height
  • DC Voltage Rating:
    250 Volt
  • Approval:
    UL
  • Neutral Type:
    Factory Installed
  • Type:
    Heavy Duty
  • Enclosure Material:
    Steel
  • Shipping Height:
    6.00 In.
  • Finish:
    Galvannealed
  • Short Circuit Current Rating
    10 kA H or K 200 kA R, J or L
  • Wire Size
    AWG 12...AWG 6 aluminium AWG 14...AWG 6 copper
  • Voltage Rating
    250 V DC 240 V AC
  • Fuse Type
    H or K R, J or L
  • Tightening Torque
    45 lbf.in (5.08 N.m) 0.02 in² (13.3 mm²) (AWG 6) 40 lbf.in (4.52 N.m) 0.01 in² (8.367 mm²) (AWG 8) 35 lbf.in (3.95 N.m) 0.00…0.01 in² (2.06…5.261 mm²) (AWG 14...AWG 10)
  • Maximum Horse Power Rating
    1.5 hp 240 V at AC 50-60 Hz for 1 phase conforming to NEC 240.6 3 hp 240 V at AC 50-60 Hz for 3 phase conforming to NEC 240.6 3 hp 240 V at AC 50-60 Hz for 1 phase conforming to NEC 430.52 7.5 hp 240 V at AC 50-60 Hz for 3 phase conforming

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
