Part#:H366

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Schneider Electric H366 is a switch-disconnector with a main function as a Heavy Duty Single Throw Safety Switch (Fused) within the Safety Switches (Heavy Duty) sub-range. It features 3 poles and is rated for a current of 600 A. The dimensions include a net height of 1276 mm, a net width of 702 mm, and a net depth of 257 mm. This switch-disconnector operates via a toggle mode. It has a short circuit breaking rating of 10kA maximum with fuse types H or K and can reach up to 200kA maximum with fuse types R, J, or L. The H366 is equipped with lugs type terminals and is designed for a rated voltage (AC) of 600 V phase-to-phase.

Product Details

  • Maximum Horse Power Rating
    150 hp 480 V at AC 50-60 Hz for 3 phase conforming to NEC 240.6 400 hp 480 V at AC 50-60 Hz for 3 phase conforming to NEC 430.52 200 hp 600 V at AC 50-60 Hz for 3 phase conforming to NEC 240.6 500 hp 600 V at AC 50-60 Hz for 3 phase conform
  • Fuse Type
    H or K R, J or L
  • Short Circuit Current Rating
    10 kA H or K 200 kA R, J or L
  • Width
    27.63 in (701.80 mm)
  • Net Weight
    179.02 lb(US) (81.2 kg)
  • Height
    50.25 in (1276.35 mm)
  • Depth
    10.13 in (257.30 mm)
  • Wiring Configuration
    3-wire
  • Tightening Torque
    375 lbf.in (42.37 N.m) (AWG 3/0...500 kcmil)
  • Wire Size
    AWG 3/0...500 kcmil copper or aluminium
  • Electrical Connection
    Lugs
  • Current Rating
    600 A
  • Mounting Type
    Surface
  • Enclosure Rating
    NEMA 1 steel
  • Voltage Rating
    600 V AC/DC
  • Duty Rating
    Heavy duty
  • Number Of Poles
    3
  • Disconnect Type
    Fusible disconnect
  • Phase
    3 phase
  • Factory Installed Neutral
    None
  • Device Application
    Heavy application
  • Product
    Single Throw Safety Switch

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of H366 on Powermatic Associates is $7,649.00. Order now.
