Part#:H363

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

Schneider Electric H363 is a switch-disconnector that falls under the sub-range of heavy-duty safety switches. This particular model is a heavy-duty single throw safety switch with a fused mechanism. It features 3 poles and is designed to handle a rated current of 100 A. The dimensions of the H363 include a net height of 540 mm, a net width of 216 mm, and a net depth of 162 mm. It operates via a toggle mode. The switch-disconnector boasts a short circuit breaking rating of 10kA maximum with fuse types H or K, and up to 200kA maximum with fuse types R, J, or L. It is equipped with lug-type terminals and is rated for a phase-to-phase voltage of 600 V AC.

Product Details

  • Current Rating
    100 A
  • Mounting Type
    Surface
  • Number Of Poles
    3
  • Enclosure Rating
    NEMA 1 steel
  • Factory Installed Neutral
    None
  • Voltage Rating
    600 V AC/DC
  • Depth
    6.38 in (162.05 mm)
  • Height
    21.25 in (539.75 mm)
  • Duty Rating
    Heavy duty
  • Disconnect Type
    Fusible disconnect
  • Net Weight
    19.84 lb(US) (9 kg)
  • Device Application
    Heavy application
  • Wiring Configuration
    3-wire
  • Phase
    3 phase
  • Product
    Single Throw Safety Switch
  • Electrical Connection
    Lugs
  • Width
    10.25 in (260.35 mm)
  • Wire Size
    AWG 12...AWG 1/0 aluminium AWG 14...AWG 1/0 copper
  • Fuse Type
    H or K R, J or L
  • Short Circuit Current Rating
    10 kA H or K 200 kA R, J or L
  • Tightening Torque
    50 lbf.in (5.65 N.m) (AWG 1...AWG 3/0) 45 lbf.in (5.08 N.m) (AWG 6...AWG 4) 40 lbf.in (4.52 N.m) 0.01 in² (8.367 mm²) (AWG 8) 35 lbf.in (3.95 N.m) 0.00…0.01 in² (2.06…5.261 mm²) (AWG 14...AWG 10)
  • Maximum Horse Power Rating
    25 hp 480 V at AC 50-60 Hz for 3 phase conforming to NEC 240.6 60 hp 480 V at AC 50-60 Hz for 3 phase conforming to NEC 430.52 30 hp 600 V at AC 50-60 Hz for 3 phase conforming to NEC 240.6 100 hp 600 V at AC 50-60 Hz for 3 phase conforming

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
