Part#:HDL26070C

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

Circuit breaker, PowerPacT H, thermal magnetic, unit mount, 70A, 2 pole, 14kA, 600 VAC, 100% rated

Product Details

  • Width
    2.74 in (69.60 mm)
  • Mounting Mode
    Unit mount
  • Magnetic Tripping Current
    1450 A
  • Depth
    4.36 in (110.74 mm)
  • Line Rated Current
    70 A
  • Continuous Current Rating
    100 %
  • Tightening Torque
    44.25 lbf.in (5 N.m) 0.00…0.15 in² (2.5…95 mm²) (AWG 14...AWG 3/0)
  • Height
    6.4 in (162.56 mm)
  • Magnetic Hold Current
    800 A
  • Product Or Component Type
    Circuit breaker
  • Range Of Product
    PowerPact H
  • Breaking Capacity Code
    D
  • Number Of Poles
    2P
  • Electrical Connection
    Lugs load Lugs line

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of HDL26070C on Powermatic Associates is $1,274.00. Order now.
