Part#:HDL26080C

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric HDL26080C is a Moulded Case Circuit Breaker (MCCB) within the PowerPacT HDL sub-range, designed with a PowerPact H-Frame 150 TMD 2P 80A 600Vac/250Vdc 14kA with lugs 100% rated. It features a connection type of lugs on both load and line sides and operates with 2 poles (2P). This MCCB offers thermal protection for overload scenarios and magnetic protection for short-circuit conditions. It has a rated current of 80A, with a rated insulation voltage (Ui) of 750 V, and supports rated voltages of 600Vac 600Y/347Vac and 250Vdc. The device is designed for individual unit mount on plate, with a net height of 163 mm, width of 104 mm, and depth of 86 mm. It provides an IP40 degree of protection and operates with a toggle (manual) mode. Protection settings include over-current fixed at 80A, short-circuit hold current fixed at 800A, and short-circuit trip current fixed at 1450A. The rated operating voltage (Ue) is 690 V, with a rated impulse voltage (Uimp) of 8 kV. The trip current rating is 80 AT, with a frame current rating of 150 AF. Its short circuit breaking rating varies with voltage, including 25kA at 240Vac, 18kA at 480Vac and 480Y/277Vac, 14kA at 600Vac and 600Y/347Vac, and 20kA at 250Vdc, all under UL489. The trip unit type is thermal-magnetic (fixed) without a display, and it falls under utilisation category A.

Product Details

  • Mounting Mode
    Unit mount
  • Number Of Poles
    2P
  • Tightening Torque
    44.25 lbf.in (5 N.m) 0.00…0.15 in² (2.5…95 mm²) (AWG 14...AWG 3/0)
  • Range Of Product
    PowerPact H
  • Height
    6.4 in (162.56 mm)
  • Magnetic Hold Current
    800 A
  • Width
    2.74 in (69.60 mm)
  • Continuous Current Rating
    100 %
  • Breaking Capacity Code
    D
  • Product Or Component Type
    Circuit breaker
  • Depth
    4.36 in (110.74 mm)
  • Line Rated Current
    80 A
  • Magnetic Tripping Current
    1450 A
  • Electrical Connection
    Lugs load Lugs line

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
