Part#:HJA260506

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

Circuit breaker, PowerPacT H, thermal magnetic, I-Line, 50A, 2 pole, 25 kA, 600 VAC, phase CB, 80% rated

Product Details

  • Phase Connection
    CB
  • Mounting Mode
    I-Line
  • Magnetic Tripping Current
    850 A
  • Height
    9.73 in (247.14 mm)
  • Breaking Capacity Code
    J
  • Range Of Product
    PowerPact H
  • Depth
    4.8 in (121.92 mm)
  • Width
    2.94 in (74.68 mm)
  • Line Rated Current
    50 A
  • Magnetic Hold Current
    400 A
  • Product Or Component Type
    Circuit breaker
  • Continuous Current Rating
    80 %
  • Tightening Torque
    44.25 lbf.in (5 N.m) 0.00…0.15 in² (2.5…95 mm²) (AWG 14...AWG 3/0)
  • Number Of Poles
    2P
  • Electrical Connection
    I-Line connection line Lugs load

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
