JGL36250CU43X Schneider Electric Electronic Components

What is the price of JGL36250CU43X?
Purchase the JGL36250CU43X from Powermatic Associates at the price of $8,689.50. Order today.

Out if stock but available for backorder.

Square D by Schneider Electric JGL36250CU43X is a Moulded Case Circuit Breaker (MCCB) within the PowerPacT JGL sub-range, featuring a PowerPact J-Frame 250 Micrologic 5.2A (LSI) design. It is a 3-pole (3P) device with a rated current of 250A and a rated insulation voltage (Ui) of 750V. This unit is designed for individual unit mount on plate, with a net height of 191 mm, width of 105 mm, and depth of 127 mm. It operates with a toggle (manual) mechanism and offers a degree of protection of IP40. The connection type includes lugs on both load and line sides. Its protection functions include Long-time protection (L), Short-time protection with fixed time delay (S), Instantaneous protection (I), and Zone Selective Interlocking (ZSI). The rated voltage (AC) is 600Vac 600Y/347Vac, with a DC rating of 500Vdc. The protection settings are adjustable for overload (0.3...1 x In), short-circuit with time delay (1.5...10 x lr), and instantaneous protection against short-circuit (1.5...12 x In). The rated operating voltage (Ue) is 690 V, with a rated impulse voltage (Uimp) of 8 kV. The trip current rating is 250 AT, and the frame current rating is 250 AF. The short circuit breaking rating varies with voltage, up to 65kA at 240Vac under UL489 standards. The trip unit type is an electronic Micrologic Ammeter 5.2A (LSI) with an LCD display, offering current measurements and calculation features for phases and neutral, including RMS instantaneous current, average current, current unbalance, highest RMS current, ground fault current, and demand/peak current values with an adjustable calculation window of 5-60min. The utilisation category is A.
