LC1D258D7 Schneider Electric Industrial Automation Components

Product Details

• Power Dissipation Per Pole
  3.2 W AC-1
• Mechanical Durability
  15 Mcycles
• Power Pole Contact Composition
  2 NO + 2 NC
• Overvoltage Category
  III
• Average Impedance
  2 mOhm - Ith 40 A 50 Hz power circuit
• Poles Description
  4P
• [Uimp] Rated Impulse Withstand Voltage
  6 kV IEC 60947
• Electrical Durability
  1.4 Mcycles 40 A AC-1 <= 440 V
• Maximum Operating Rate
  3600 cyc/h 140 °F (60 °C)
• Heat Dissipation
  2…3 W 50/60 Hz
• Contactor Application
  Resistive load
• Control Circuit Type
  AC 50/60 Hz
• Auxiliary Contact Composition
  1 NO + 1 NC
• Front Cover
  With
• Minimum Switching Current
  5 mA signalling circuit
• Product Or Component Type
  Contactor
• [Uc] Control Circuit Voltage
  42 V AC 50/60 Hz
• Rated Breaking Capacity
  450 A 440 V power circuit IEC 60947
• Signalling Circuit Frequency
  25...400 Hz
• Product Name
  TeSys D
[Ie] Rated Operational Current
40 A 140 °F (60 °C)) <= 440 V AC AC-1 power circuit
Coil Technology
Without built-in suppressor module
Insulation Resistance
> 10 MOhm signalling circuit
Device Short Name
LC1D
Range
TeSys
Utilisation Category
AC-1
Minimum Switching Voltage
17 V signalling circuit
Safety Reliability Level
B10d = 1369863 cycles contactor with nominal load EN/ISO 13849-1 B10d = 20000000 cycles contactor with mechanical load EN/ISO 13849-1
Inrush Power In VA
70 VA 60 Hz 0.75 68 °F (20 °C)) 70 VA 50 Hz 0.75 68 °F (20 °C))
[Ue] Rated Operational Voltage
Power circuit <= 690 V AC 25...400 Hz Power circuit <= 300 V DC
Hold-In Power Consumption In VA
7.5 VA 60 Hz 0.3 68 °F (20 °C)) 7 VA 50 Hz 0.3 68 °F (20 °C))
Mounting Support
Rail Plate
Operating Time
12...22 ms closing 4...19 ms opening
[Ith] Conventional Free Air Thermal Current
10 A 140 °F (60 °C) signalling circuit 40 A 140 °F (60 °C) power circuit
Auxiliary Contacts Type
Mechanically linked 1 NO + 1 NC IEC 60947-5-1 Mirror contact 1 NC IEC 60947-4-1
Non-Overlap Time
1.5 ms on de-energisation between NC and NO contact 1.5 ms on energisation between NC and NO contact
Irms Rated Making Capacity
140 A AC signalling circuit IEC 60947-5-1 250 A DC signalling circuit IEC 60947-5-1 450 A 440 V power circuit IEC 60947
Associated Fuse Rating
10 A gG signalling circuit IEC 60947-5-1 63 A gG <= 690 V type 1 power circuit 40 A gG <= 690 V type 2 power circuit
Connections - Terminals
Control circuit screw clamp terminals 1 0.00…0.01 in² (1…4 mm²)flexible without cable end Control circuit screw clamp terminals 2 0.00…0.01 in² (1…4 mm²)flexible without cable end Control circuit screw clamp terminals 1 0.00…0.01 in² (1…4 mm²)fl
Control Circuit Voltage Limits
0.3...0.6 Uc -40…158 °F (-40…70 °C) drop-out AC 50/60 Hz 0.8...1.1 Uc -40…140 °F (-40…60 °C) operational AC 50 Hz 0.85...1.1 Uc -40…140 °F (-40…60 °C) operational AC 60 Hz 1...1.1 Uc 140…158 °F (60…70 °C) operational AC 50/60 Hz
Tightening Torque
Control circuit 15.05 lbf.in (1.7 N.m) screw clamp terminals flat Ø 6 mm Control circuit 15.05 lbf.in (1.7 N.m) screw clamp terminals Philips No 2 Power circuit 15.93 lbf.in (1.8 N.m) connector flat Ø 6 mm Power circuit 15.93 lbf.in (1.8 N.
[Ui] Rated Insulation Voltage
Power circuit 690 V IEC 60947-4-1 Power circuit 600 V CSA Power circuit 600 V UL Signalling circuit 690 V IEC 60947-1 Signalling circuit 600 V CSA Signalling circuit 600 V UL
[Icw] Rated Short-Time Withstand Current
240 A 104 °F (40 °C) - 10 s power circuit 380 A 104 °F (40 °C) - 1 s power circuit 50 A 104 °F (40 °C) - 10 min power circuit 120 A 104 °F (40 °C) - 1 min power circuit 100 A - 1 s signalling circuit 120 A - 500 ms signalling circ
Standards
CSA C22.2 No 14 EN 60947-4-1 EN 60947-5-1 IEC 60947-4-1 IEC 60947-5-1 UL 508
Product Certifications
RINA GL DNV GOST LROS (Lloyds register of shipping) CCC BV UL CSA
