Part#:LP1K12004BD

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Schneider Electric LP1K12004BD is a magnetic contactor within the K sub-range, featuring screw connections and a 4-pole (4P; 4NO) configuration. It has a rated current of 20A (AC-1) and 144A (Irms AC), with a net width of 45 mm. This contactor offers a degree of protection of IP20 and operates with a control voltage (DC) range of 19.2-27.6Vdc (24Vdc nominal; 0.8...1.15 x Uc). The rated operating voltage (Ue) is up to 690 V, and it comes without normally open (NO) or normally closed (NC) auxiliary contacts. Its mechanical durability is rated at 10,000,000 operations at no load, and the rated voltage (AC) for phase-to-phase is 690 V.

Product Details

  • Mechanical Durability
    10 Mcycles
  • Range
    TeSys
  • [Uimp] Rated Impulse Withstand Voltage
    8 kV
  • Device Short Name
    LP1K
  • Pole Contact Composition
    4 NO
  • Poles Description
    4P
  • Contactor Application
    Resistive load
  • Hold-In Power Consumption In W
    3 W 68 °F (20 °C)
  • Product Or Component Type
    Contactor
  • [Ue] Rated Operational Voltage
    Power circuit 690 V AC 50/60 Hz
  • Maximum Operating Rate
    3600 cyc/h
  • Overvoltage Category
    III
  • Utilisation Category
    AC-1
  • Net Weight
    0.50 lb(US) (0.225 kg)
  • Range Of Product
    TeSys K
  • [Ith] Conventional Free Air Thermal Current
    20 A 122 °F (50 °C) power circuit
  • Height
    2.28 in (58 mm)
  • Width
    1.77 in (45 mm)
  • Average Impedance
    3 mOhm - Ith 20 A 50 Hz power circuit
  • Depth
    2.24 in (57 mm)
  • Inrush Power In W
    3 W 68 °F (20 °C))
  • Tightening Torque
    11.51 lbf.in (1.3 N.m) screw clamp terminals Philips No 2 11.51 lbf.in (1.3 N.m) screw clamp terminals flat Ø 6 mm
  • Mounting Support
    Plate Rail
  • Control Circuit Voltage Limits
    Operational: 0.8...1.15 Uc (at <50 °C) Drop-out 0.1...0.75 Uc 122 °F (50 °C))
  • Safety Reliability Level
    B10d = 1369863 cycles contactor with nominal load EN/ISO 13849-1 B10d = 20000000 cycles contactor with mechanical load EN/ISO 13849-1
  • [Ie] Rated Operational Current
    20 A 122 °F (50 °C)) <= 440 V AC AC-1 power circuit 16 A 158 °F (70 °C)) 690 V AC AC-1 power circuit
  • Operating Time
    30...40 ms coil energisation and NO closing 10 ms coil de-energisation and NO opening
  • Irms Rated Making Capacity
    144 A AC power circuit NF C 63-110 144 A AC power circuit IEC 60947
  • Associated Fuse Rating
    25 A gG <= 440 V power circuit 25 A aM power circuit
  • Rated Breaking Capacity
    110 A 440 V IEC 60947 80 A 500 V IEC 60947 70 A 660...690 V IEC 60947
  • Flame Retardance
    V1 conforming to UL 94 Requirement 2 conforming to NF F 16-101 Requirement 2 conforming to NF F 16-102
  • [Ui] Rated Insulation Voltage
    Power circuit 600 V UL 508 Power circuit 690 V IEC 60947-4-1 Power circuit 600 V CSA C22.2 No 14

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of LP1K12004BD on Powermatic Associates is $97.42. Order now.

LP1K12004BD Related Documents

Instruction Sheet-1631038787100.pdfProduct Datasheet-1631038787102.pdf
