LR2K0305 Schneider Electric Industrial Automation Components

Product Details

• Network Frequency
  <= 400 Hz
• Height
  2.28 in (58 mm)
• Relay Application
  Motor protection
• Power Dissipation Per Pole
  2 W
• Thermal Overload Class
  Class 10A IEC 60947-4-1
• [Uimp] Rated Impulse Withstand Voltage
  6 kV
• Range
  TeSys
• Thermal Protection Adjustment Range
  0.54…0.8 A
• Local Signalling
  Trip indicator Yellow)
• Net Weight
  0.32 lb(US) (0.145 kg)
• Device Short Name
  LR2K
• [Ith] Conventional Free Air Thermal Current
  6 A signalling circuit
• Auxiliary Contact Composition
  1 NO + 1 NC
• Depth
  2.56 in (65 mm)
• Product Or Component Type
  Differential thermal overload relay
• Width
  1.77 in (45 mm)
• Product Name
  TeSys LRK
• Phase Failure Sensitivity
  Yes IEC 60947-4-1
• Network Type
  DC AC
• Tightening Torque
  11.51 lbf.in (1.3 N.m) screw clamp terminals Philips No 2 11.51 lbf.in (1.3 N.m) screw clamp terminals flat Ø 6 mm
Associated Fuse Rating
6 A gG signalling circuit VDE 0660 6 A gG signalling circuit IEC 60947
[Ue] Rated Operational Voltage
<= 690 V power circuit 690 V AC AC-15 signalling circuit 250 V DC DC-13 signalling circuit
Control Type
Red push-button trip test function Blue push-button stop and manual reset selector switch manual or automatic reset
Mounting Support
Under contactor Plate, with specific accessories Rail, with specific accessories
Connections - Terminals
screw clamp terminals 1 0.00…0.01 in² (1.5…4 mm²)solid screw clamp terminals 2 0.00…0.01 in² (1.5…4 mm²)solid screw clamp terminals 1 0.00…0.01 in² (0.75…4 mm²)flexible without cable end screw clamp terminals 2 0.00…0.01 in² (0.75…4 mm²)
[Ui] Rated Insulation Voltage
Power circuit 690 V BS 4941 Power circuit 690 V IEC 60947 Power circuit 750 V VDE 0110 group C Power circuit 600 V CSA C22.2 No 14
Product Compatibility
LP4K LC1K LP1K LC7K
