Schneider Electric

Part#:LV426995

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric LV426995 is a mounting accessory designed for FA to PowerPact B-frame 9421 rotational handle conversion plate kit.

Product Details

  • Circuit Breaker Name
    PowerPact B
  • Range Of Product
    Powerpact
  • Product Or Component Type
    Rotary handle kit

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of LV426995 on Powermatic Associates is $12.00. Order now.
