PGF36040CU31A Schneider Electric Electronic Components

PGF36040CU31A on Powermatic Associates
Schneider Electric

Part#:PGF36040CU31A

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

Molded Case Circuit Breaker 600V 400A

Product Details

  • Poles Description
    3P
  • Depth
    8.05 in (204.47 mm)
  • Product Or Component Type
    Circuit breaker
  • Mounting Mode
    Unit mount
  • Height
    12.86 in (326.64 mm)
  • Module Type
    P-Frame
  • Width
    8.27 in (210.06 mm)
  • Device Short Name
    A
  • Trip Unit Technology
    Electronic, standard, Micrologic 3.0, LI
  • Range
    PowerPact P
  • Mounting Location
    Busbar
  • Rated Operatioal Voltage
    600 V AC
  • Continuous Current Rating
    100 %
  • Current Sensor Rating Range
    400 A
  • Rated Current
    400 A
  • Circuit Breaker Rating Code
    G
  • Electrical Connection
    Busbar connection line Busbar connection load
  • Tightening Torque
    442.54 lbf.in (50 N.m) 0.15…0.37 in² (95…240 mm²) (AWG 3/0...500 kcmil) 8.85…11.51 lbf.in (1.0…1.3 N.m)
  • Breaking Capacity
    65 kA 240 V AC 35 kA 480 V AC 18 kA 600 V AC
  • Certifications
    UL Listed CSA IEC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

PGF36040CU31A Related Documents

Product Datasheet-1631028976968.pdfCatalog-1631028976957.pdf
