PGL36100U41A Schneider Electric Industrial Automation Components

PGL36100U41A on Powermatic Associates
Schneider Electric

Part#:PGL36100U41A

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric PGL36100U41A is a Molded Case Circuit Breaker (MCCB) designed for mounting on a plate. It features a rated current of 1000A with lugs for both load and line side connections, falling under the PowerPact PGL sub-range. This 3-pole MCCB operates at a rated voltage of 600V AC and includes a comprehensive suite of protection functions: Long-time (L), Short-time with fixed time delay (S), Instantaneous (I), and Ground fault (G). It has a trip current rating of 1000 AT and a frame current rating of 1200 AF. The short circuit breaking ratings are specified as 65kA at 240Vac, 35kA at both 480Y/277Vac and 480Vac, and 18kA at both 600Y/347Vac and 600Vac. All three poles are protected, and it utilizes an ET6.0A (LSIG) Electronic trip unit.

Product Details

  • Electrical Connection
    Lugs load Lugs line
  • Tightening Torque
    442.54 lbf.in (50 N.m) 0.15…0.37 in² (95…240 mm²) (AWG 3/0...500 kcmil) 8.85…11.51 lbf.in (1.0…1.3 N.m)
  • Continuous Current Rating
    80 %
  • Number Of Poles
    3P
  • Depth
    8.05 in (204.47 mm)
  • Device Short Name
    A
  • Line Rated Current
    1000 A
  • Width
    8.27 in (210.06 mm)
  • Breaking Capacity Code
    G
  • Height
    16.16 in (410.46 mm)
  • Product Or Component Type
    Circuit breaker

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of PGL36100U41A on Powermatic Associates is $20,688.00. Order now.
