Part#:QBM22200TN

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric QBM22200TN is a Moulded Case Circuit Breaker (MCCB) designed for individual unit mount on plate. It features a PowerPact Q-Frame 250 TMD 2P 200A 240Vac 10kA lug ON end 80% rated top of panel design, with a net height of 114 mm, width of 164 mm, and depth of 100 mm. This 2-pole (2P) circuit breaker has a rated current of 200A and operates at a rated voltage of 240Vac. The connection type includes threaded studs (with nuts) on the load side and lugs connection on the line side. It belongs to the PowerPacT QBM sub-range and offers a rated operating voltage (Ue) of 240 V. The protection functions include thermal protection for overload and magnetic protection for short-circuit, with trip current rating set at 200 AT and frame current rating at 250 AF. Its short circuit breaking rating is 10kA (240Vac; UL489). The trip unit type is thermal-magnetic (fixed) with no display. It is categorized under utilisation category A, with protection settings over-current fixed at 200A, short-circuit hold current fixed at 1200A, and short-circuit trip current fixed at 2400A.

Product Details

  • Product Or Component Type
    Circuit breaker
  • Height
    6.47 in (164.34 mm)
  • Line Rated Current
    200 A
  • Width
    4.5 in (114.30 mm)
  • Magnetic Hold Current
    1200 A
  • Depth
    3.93 in (99.82 mm)
  • Tightening Torque
    247.82 lbf.in (28 N.m) 0.04…0.23 in² (25…150 mm²) (AWG 4...300 kcmil)
  • Breaking Capacity Code
    B
  • Continuous Current Rating
    80 %
  • Magnetic Tripping Current
    2400 A
  • Trip Unit Technology
    Thermal-magnetic

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of QBM22200TN on Powermatic Associates is $474.00. Order now.
