QO270CP Schneider Electric Industrial Automation Components

QO270CP on Powermatic Associates
Schneider Electric

Part#:QO270CP

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Schneider Electric - QO270CP

Product Details

  • Mounting Type
    Plug-in
  • Tightening Torque
    44.25 lbf.in (5 N.m) 0.02…0.04 in² (10…25 mm²) (AWG 8...AWG 2)
  • Ratings
    HACR rated
  • Number Of Panel Spaces
    2
  • Number Of Poles
    2P
  • Height
    3.12 in (79.25 mm)
  • Current Rating
    70 A
  • Depth
    2.91 in (73.91 mm)
  • Range
    QO
  • Width
    1.5 in (38.10 mm)
  • Electrical Connection
    Box lugs
  • Circuit Breaker Type
    Standard
  • Type Of Packing
    Consumer packaging
  • Product
    Miniature circuit-breaker
  • Wire Size
    AWG 8...AWG 2 copper or aluminium
  • Interrupt Rating
    10 kA 120/240 V AC 50/60 Hz 10 kA 120 V AC 50/60 Hz 5 kA 48 V DC
  • Voltage Rating
    120/240 V AC 120 V AC 48 V DC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
