QOB140VH1021 Schneider Electric Electronic Components

QOB140VH1021 on Powermatic Associates
Schneider Electric

Part#:QOB140VH1021

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

Mini CB, QO, 40 A, 1P, 120/240 V, 22 kA, Bolt on, Shunt Trip

Product Details

  • Number Of Panel Spaces
    2
  • Product
    Miniature circuit-breaker
  • Circuit Breaker Type
    Standard
  • Height
    3 in (76.20 mm)
  • Ratings
    HACR rated
  • Range
    QO
  • Mounting Type
    Bolt-on
  • Wire Size
    AWG 14...AWG 8 copper or aluminium
  • Electrical Connection
    Pressure plate
  • Number Of Poles
    1P
  • Depth
    2.91 in (73.91 mm)
  • Current Rating
    40 A
  • Options
    Shunt trip 120/208/240 V AC
  • Tightening Torque
    44.25 lbf.in (5 N.m) 0.02…0.04 in² (10…25 mm²) (AWG 8...AWG 2)
  • Width
    1.5 in (38.10 mm)
  • Interrupt Rating
    22 kA 120/240 V AC 50/60 Hz 22 kA 120 V AC 50/60 Hz
  • Voltage Rating
    120/240 V AC 120 V AC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of QOB140VH1021 on Powermatic Associates is $275.00. Order now.
