QOB21035 Schneider Electric Industrial Automation Components

QOB21035 on Powermatic Associates
Schneider Electric

Part#:QOB21035

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric QOB21035 is a Miniature Circuit Breaker (MCB) designed for bolt-on mounting. It features a rated current of 10A and accommodates a bolt-on connection type. This MCB is compatible with a voltage rating of 48Vdc and 120/240Vac, supporting a cross-section of 14-8AWG for 1 cable Al/Cu. It is a 2 Pole device with a short circuit breaking rating of 10kA at 240Vac and 5kA at 48Vdc. The terminals are of the press plate type.

Product Details

  • Number Of Poles
    2P
  • Wire Size
    AWG 14...AWG 8 copper or aluminium
  • Range
    QO
  • Ratings
    Not rated
  • Number Of Panel Spaces
    2
  • Current Rating
    10 A
  • Tightening Torque
    40.71 lbf.in (4.6 N.m)
  • Height
    3 in (76.20 mm)
  • Circuit Breaker Type
    Standard
  • Width
    1.5 in (38.10 mm)
  • Mounting Type
    Bolt-on
  • Depth
    2.91 in (73.91 mm)
  • Product
    Miniature circuit-breaker
  • Electrical Connection
    Pressure plate
  • Interrupt Rating
    10 kA 120/240 V AC 50/60 Hz 10 kA 120 V AC 50/60 Hz 5 kA 48 V DC
  • Voltage Rating
    120/240 V AC 120 V AC 48 V DC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of QOB21035 on Powermatic Associates is $107.00. Order now.

QOB21035 Related Documents

Product Datasheet-1631031125903.pdfCatalog-1631031125915.pdf
