VLVAW3N76250AB Schneider Electric Electronic Components

VLVAW3N76250AB on Powermatic Associates
Schneider Electric

Part#:VLVAW3N76250AB

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

VarSet capacitor bank Auto with incoming CB 600V 60Hz 250kvar

Product Details

  • Poles Description
    3P
  • Device Short Name
    VarSet standard
  • Power Per Step
    50 kvar
  • Capacitor Technology
    VarPlus Can
  • Location Of Connection
    Top
  • Mounting Location
    Indoor
  • Range Of Product
    VarSet
  • Color
    Gray RAL 7035)
  • Capacitance Tolerance
    - 5 % to 10 %
  • Operating Mode
    Automatic
  • Accessibility For Operation
    Front
  • Maximum Permissible Voltage
    1.1 x Un (8 hours over 24 hours)
  • Network Rated Voltage
    600 V AC 60 Hz
  • [Thdv] Total Harmonic Distortion
    0…3 %
  • Reactive Power Rating
    250 kvar
  • Step Composition
    5x50
  • Product Or Component Type
    Capacitor bank
  • Internal Voltage Transformer
    600/120 V
  • Control Type
    Rotary handle
  • Network Pollution Level
    No polluted
  • Protection Type
    Circuit breaker protection
  • Controller Type
    Varplus Logic VPL6 Modbus
  • Breaking Capacity
    50 kA
  • Width
    39.37 in (1000 mm) 39.4 in (1000.76 mm)
  • Depth
    15.75 in (400 mm) 15.7 in (398.78 mm)
  • Height
    47.24 in (1200 mm) 47.2 in (1198.88 mm)
  • Maximum Weight
    275.58 lb(US) (125 kg) 275 lb(US) (124.74 kg)

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of VLVAW3N76250AB on Powermatic Associates is $66,054.50. Order now.
