XACA08XGCC Schneider Electric Electronic Components

XACA08XGCC on Powermatic Associates
Schneider Electric

Part#:XACA08XGCC

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

PENDANT STATION 600VAC 10AMP XAC SPECIAL

Product Details

  • Electrical Circuit Type
    Control circuit
  • Device Short Name
    XACA
  • Ambient Air Temperature For Operation
    -13…158 °F (-25…70 °C)
  • Product Or Component Type
    Pendant control station
  • Range Of Product
    Harmony XAC
  • IP Degree Of Protection
    IP65 conforming to IEC 60529
  • Enclosure Type
    Complete ready for use
  • Protective Treatment
    TH
  • IK Degree Of Protection
    IK08 EN 50102
  • Vibration Resistance
    15 gn 10…500 Hz)IEC 60068-2-6
  • Enclosure Material
    Polypropylene
  • Control Station Composition
    8 push-buttons
  • Ambient Air Temperature For Storage
    -40…158 °F (-40…70 °C)
  • Mechanical Durability
    1000000 cycles
  • Control Station Type
    Double insulated
  • Overvoltage Category
    Class II conforming to IEC 61140
  • Connections - Terminals
    Screw clamp terminals, 1 x 2.5 mm² with or without cable end Screw clamp terminals, 2 x 1.5 mm² with or without cable end

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
