XVR13M04L Schneider Electric Industrial Automation Components

XVR13M04L on Powermatic Associates
Schneider Electric

Part#:XVR13M04L

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Schneider Electric XVR13M04L is a revolving warning light, part of the XVR sub-range, designed with a squared-off dome shape. It features a rotating mirror beacon function and emits a red light. This model offers a degree of protection rated at IP66, making it suitable for environments where dust and water resistance are necessary. It operates with a control and supply voltage of 230 Vac and has a diameter of 130 mm.

Product Details

  • Device Short Name
    XVR
  • Marking
    CE
  • Clamping Connection Capacity
    1.25 mm²
  • Light Source
    High luminosity LED, red
  • Mounting Diameter
    5.12 in (130 mm)
  • Current Consumption
    22 mA
  • Product Or Component Type
    Prewired rotating mirror beacon
  • CAD Overall Width
    5.12 in (130 mm)
  • Flashing Frequency
    2.7 Hz
  • [Us] Rated Supply Voltage
    230 V AC
  • Product Mounting
    By 3 M6 screws
  • Sound Signalling
    Without
  • Net Weight
    2.18 lb(US) (0.99 kg)
  • AWG Gauge
    AWG 18
  • Range Of Product
    Harmony XVR
  • CAD Overall Depth
    5.12 in (130 mm)
  • Cable Length
    15.75 in (400 mm)
  • [Uimp] Rated Impulse Withstand Voltage
    4 kV
  • Material
    ABS (acrylonitrile butadiene-styrene) body part PC globe
  • IP Degree Of Protection
    IP66 IEC 60529 IP67 IEC 60529

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of XVR13M04L on Powermatic Associates is $207.00. Order now.
