PS250R-301-LI2UPN8X-H1141 Turck Industrial Automation Components
Part#:PS250R-301-LI2UPN8X-H1141
Alt. Part#:6833309
Manufacturer:Turck
Category:Industrial Automation Components
Product Lifecycle:Active
Product description
PS250R-301-LI2UPN8X-H1141 Turck - PS250R-301-LI2UPN8X-H1141 Pressure sensor, With Analog Output and PNP/NPN Transistor Switching Output, Output 2 Reprogrammable as Switching Output
Product Details
- Weight 255 g
- RoHS Yes
- Country Of Origin DEU
- HTS Code 9026204000
- Operating voltage 18…30 VDC
- Medium temperature -40…+85 °C
- Pressure type Relative pressure
- Voltage output 0…10 V
- Pressure transducer material Ceramics Al
2 O3 - Process connection G 1/4'' female thread
- Electrical connection Connector, M12 × 1
- Protection class IP67/IP69K
- Current output 4…20 mA
- Design With display
- Communication protocol IO-Link
- Relative pressure psi 0…3625.95 psi rel.
- Housing material Stainless-steel/Plastic, 1.4305 (AISI 303)
- Relative pressure bar 0…250 bar rel.
- Electrical output Current output (3-wire), 2 × switching output
- Ambient temperature -40…+80 °C
- Weight 255 grams
- Country of Origin Germany
- Operating Voltage 18 volts, 30 volts
- Ambient Temperature -40 degrees celsius, 80 degrees celsius
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of PS250R-301-LI2UPN8X-H1141 on Powermatic Associates is $637.70. Order now.
About the product
Pressure sensor, With Analog Output and PNP/NPN Transistor Switching Output, Output 2 Reprogrammable as Switching Output, , Rigid process connection, non-rotatable body, Reading of adjusted values without tool, Recessed pushbutton and keylock for secure programming, Permanent indication of pressure (bar, psi, kPa, MPa, misc), Peak pressure memory, Pressure range 0…250 bar rel.
