REI-E-112I8E-2B1024-C Turck Industrial Automation Components

REI-E-112I8E-2B1024-C on Powermatic Associates
Turck

Part#:REI-E-112I8E-2B1024-C

Alt. Part#:100012061

Manufacturer:Turck

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

REI-E-112I8E-2B1024-C Turck - REI-E-112I8E-2B1024-C Incremental Encoder, Efficiency Line

Product Details

  • Weight
    256 g
  • Country Of Origin
    IND
  • HTS Code
    9032894000
  • Output type
    Incremental
  • Protection class
    IP64
  • Operating voltage
    10…30 VDC
  • Encoder line
    Efficiency-Line
  • Protection class shaft
    IP64
  • Resolution, incremental
    1024  ppr
  • Flange type
    Flange with stator coupling
  • Shaft diameter D [mm]
    8  mm
  • Technology
    Optical
  • Shaft Type
    Hollow shaft
  • Housing material
    Aluminium
  • Flange diameter
    Ø  46  mm
  • Electrical connection
    Cable
  • Ambient temperature
    -20…+70 °C
  • Output function
    Push-Pull/HTL, with inverted signals
  • Country of Origin
    India
  • Weight
    256 grams
  • Ambient Temperature
    -20 degrees celsius, 70 degrees celsius
  • Operating Voltage
    10 volts, 30 volts

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of REI-E-112I8E-2B1024-C on Powermatic Associates is $225.20. Order now.

About the product

Incremental Encoder, Efficiency Line, Resolution, incremental 1024 ppr, Flange with stator coupling, Ø 46 mm, Blind hole hollow shaft, Ø 8 mm (plug-in depth max. 18 mm), Optical measuring principle, Shaft material: stainless steel, Protection class IP64 on housing and shaft side, ‐20…+70 °C, Max. 4500 rpm, 10…30 VDC, Cable connection, 8-pole, Push-pull, with inverted signals, Pulse frequency max. 300 kHz, 1024 pulses per revolution
