REI-E-114I8E-2B360-H1181 Turck Industrial Automation Components
Part#:REI-E-114I8E-2B360-H1181
Manufacturer:Turck
Category:Industrial Automation Components
Product Lifecycle:Discontinued
Product description
REI-E-114I8E-2B360-H1181 Turck - REI-E-114I8E-2B360-H1181 Incremental Encoder, Efficiency Line
Product Details
- Shaft Type Hollow shaft
- Technology Optical
- Shaft diameter D [mm] 8 mm
- Electrical connection Connector, M12 × 1
- Protection class IP64
- Operating voltage 10…30 VDC
- Flange diameter Ø 63 mm
- Encoder line Efficiency-Line
- Housing material Die-cast zinc
- Resolution, incremental 360 ppr
- Output function Push-Pull/HTL, with inverted signals
- Output type Incremental
- Protection class shaft IP64
- Flange type Flange with stator coupling
- Ambient temperature -20…+70 °C
- Operating Voltage 10 volts, 30 volts
- Weight 400 grams
- Country of Origin India
- Ambient Temperature -20 degrees celsius, 70 degrees celsius
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
About the product
Incremental Encoder, Efficiency Line, Resolution, incremental 360 ppr, Flange with stator coupling, Ø 63 mm, Hollow shaft, Ø 8mm, Optical measuring principle, Shaft material: stainless steel, Protection class IP64 on housing and shaft side, ‐20…+70 °C, Max. 4500 rpm (continuous operation 3000 rpm), 10…30 VDC, Male connector, M12 x 1, 8-pole, Push-pull, with inverted signals, Pulse frequency max. 300 kHz, 360 pulses per revolution
REI-E-114I8E-2B360-H1181 Related Documents
Similar products from: Turck Industrial Automation Components
Manufacturer warranty
REI-E-114I8E-2B360-H1181 Turck
Get a quick Quote!
Request a quote, and we will send you price and availability within minutes.
Select Qty:
Average response time: 11 minutes
Worldwide Shipping and Delivery
Secure Payment Processing
Warranty
Responsive Customer Support
Got Questions? We've Got Answers!
Need more details?
Feel free to chat with us
Compare REI-E-114I8E-2B360-H1181 with other Industrial Automation Components products
Shaft Type
Technology
Shaft diameter D [mm]
Electrical connection
Protection class
Operating voltage
Flange diameter
Encoder line
Housing material
Resolution, incremental
Selected product
REI-E-114I8E-2B360-H1181
Turck
REI-E-114I8E-2B360-H1181 Turck - REI-E-114I8E-2B360-H1181 Incremental Encoder, Efficiency Line
Shaft TypeHollow shaft
TechnologyOptical
Shaft diameter D [mm]8 mm
Electrical connectionConnector, M12 × 1
Protection classIP64
Operating voltage10…30 VDC
Flange diameterØ 63 mm
Encoder lineEfficiency-Line
Housing materialDie-cast zinc
Resolution, incremental360 ppr
RI60P2-QR20-LU4X2
Turck
RI60P2-QR20-LU4X2 Turck - RI60P2-QR20-LU4X2 Miniature Encoder, With Analog Output, Premium Line
Shaft TypeBlind hole shaft
TechnologyContactless
Shaft diameter D [mm]6 mm6.35 mm
Electrical connection-
Protection class-
Operating voltage8…30 VDC
Flange diameter-
Encoder linePremium-Line
Housing material-
Resolution, incremental-
BI1.5-EG08F-AN6X
Turck
BI1.5-EG08F-AN6X Turck - BI1.5-EG08F-AN6X Inductive Sensor, Stainless Steel Front
Shaft Type-
Technology-
Shaft diameter D [mm]-
Electrical connection-
Protection class-
Operating voltage10…30 VDC
Flange diameter-
Encoder line-
Housing material-
Resolution, incremental-
About the manufacturer
Powermatic Associates is an authorized Turck distributor, committed to delivering top-tier industrial solutions that align with your operational requirements. Turck is a globally recognized provider of advanced automation technology, specializing in sensor, connectivity, and fieldbus technology. Their extensive product range includes robust sensors such as inductive, capacitive, photoelectric, and...
