REM-190SA0S-IOL32B-H1141 Turck Industrial Automation Components
Part#:REM-190SA0S-IOL32B-H1141
Alt. Part#:100018242
Manufacturer:Turck
Category:Industrial Automation Components
Product Lifecycle:Active
Product description
REM-190SA0S-IOL32B-H1141 Turck - REM-190SA0S-IOL32B-H1141 Absolute Rotary Encoder - Multiturn, IO-Link, Industrial Line
Product Details
- Weight 286 g
- Country Of Origin DEU
- HTS Code 9032894000
- Flange diameter Ø 36 mm
- Shaft Type Solid shaft
- Operating voltage 18…30 VDC
- Output type Absolute multiturn
- Protection class shaft IP67
- Technology Magnetic
- Ambient temperature -40…+85 °C
- Shaft diameter D [mm] 6.35 mm
- Electrical connection Connector, M12 × 1
- Flange type Synchro flange
- Protection class IP67
- Communication protocol IO-Link
- Encoder line Industrial-Line
- Housing material Die-cast zinc
- Operating Voltage 18 volts, 30 volts
- Country of Origin Germany
- Weight 286 grams
- Ambient Temperature -40 degrees celsius, 85 degrees celsius
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of REM-190SA0S-IOL32B-H1141 on Powermatic Associates is $635.70. Order now.
About the product
Absolute Rotary Encoder - Multiturn, IO-Link, Industrial Line, Synchro flange, Ø 36 mm, Solid shaft, Ø 6.35 mm × 12.5 mm, Magnetic measuring principle, Shaft material: stainless steel, IP67 rated on the shaft side, ‐40…+85 °C, Max. 4000 rev/min, , 18….30 VDC, M12 x 1 male connection, 4-pin, Singleturn resolution 14 bit scalable, default 14 bit, Multiturn resolution scalable only to 18 bits over total resolution, default 18 bits, Total resolution 32 bit scalable, default 32 bit
