REM-191B6T-IOL32B-H1141 Turck Industrial Automation Components

Name: REM-191B6T-IOL32B-H1141
Brand: Turck
Price: 635.7 USD
Availability: BackOrder

REM-191B6T-IOL32B-H1141 on Powermatic Associates

Part#:REM-191B6T-IOL32B-H1141

Alt. Part#:100018247

Manufacturer:Turck

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

REM-191B6T-IOL32B-H1141 Turck - REM-191B6T-IOL32B-H1141 Absolute Rotary Encoder - Multiturn, IO-Link, Industrial Line

Product Details

Weight
317 g
Country Of Origin
DEU
HTS Code
9032894000
Output type
Absolute multiturn
Protection class shaft
IP67
Encoder line
Industrial-Line
Protection class
IP67
Shaft Type
Blind hole shaft
Ambient temperature
-40…+85 °C
Operating voltage
18…30 VDC
Shaft diameter D [mm]
6 mm
Flange type
Flange with mounting element
Electrical connection
Connector, M12 × 1
Communication protocol
IO-Link
Technology
Magnetic
Housing material
Die-cast zinc
Flange diameter
Ø 36 mm
Weight
317 grams
Operating Voltage
18 volts, 30 volts
Ambient Temperature
-40 degrees celsius, 85 degrees celsius

Country of Origin

Germany

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of REM-191B6T-IOL32B-H1141 on Powermatic Associates is $635.70. Order now.

About the product

Absolute Rotary Encoder - Multiturn, IO-Link, Industrial Line, Flange with long torque stop, Hollow shaft, Ø 6mm, Optical measuring principle, Shaft material, stainless steel, , IP67 rated on the shaft side, ‐40…+85 °C, Max. 4000 rev/min, , 18….30 VDC, M12 x 1 male connection, 4-pin, Singleturn resolution 14 bit scalable, default 14 bit, Multiturn resolution scalable only to 18 bits over total resolution, default 18 bits, Total resolution 32 bit scalable, default 32 bit
