RI-43H25E2-1B50-H1181 Turck Industrial Automation Components

Name: RI-43H25E2-1B50-H1181
Brand: Turck

RI-43H25E2-1B50-H1181 on Powermatic Associates

Part#:RI-43H25E2-1B50-H1181

Manufacturer:Turck

Category:Industrial Automation Components

Product Lifecycle:Discontinued

Product description

RI-43H25E2-1B50-H1181 Turck - RI-43H25E2-1B50-H1181 Incremental Hollow Shaft Encoder, Industrial Line

Product Details

Shaft diameter D [mm]
25 mm
Protection class
IP65
Flange type
Flange with mounting element
Housing material
Die-cast zinc
Resolution, incremental
50 ppr
Protection class shaft
IP65
Output type
Incremental
Ambient temperature
-40…+80 °C
Encoder line
Industrial-Line
Operating voltage
10…30 VDC
Output function
Push-Pull/HTL, non-invertable
Shaft Type
Hollow shaft
Electrical connection
Connector, M12 × 1
Technology
Optical
Flange diameter
Ø 100 mm
Operating Voltage
10 volts, 30 volts
Ambient Temperature
-40 degrees celsius, 80 degrees celsius

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

About the product

Incremental Hollow Shaft Encoder, Industrial Line, Resolution, incremental 50 ppr, Incremental Hollow Shaft Encoder, Protection class IP65 on the shaft side, ‐40 ... +80°C, max. 6000 rev / min, 10…30 VDC, Male connector, M12 x 1, 8-pole, Push-pull, without inverted signals, Pulse frequency max. 300 kHz, 50 pulses per revolution
