RI-43H38S8-2F2048-C1M Turck Industrial Automation Components

Name: RI-43H38S8-2F2048-C1M
Brand: Turck
Price: 630 USD
Availability: BackOrder

RI-43H38S8-2F2048-C1M on Powermatic Associates

Part#:RI-43H38S8-2F2048-C1M

Alt. Part#:1545467

Manufacturer:Turck

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

RI-43H38S8-2F2048-C1M Turck - RI-43H38S8-2F2048-C1M Incremental Hollow Shaft Encoder, Industrial Line

Product Details

RoHS
Yes
Country Of Origin
USA
HTS Code
9029108000
Flange diameter
Ø 100 mm
Ambient temperature
-40…+80 °C
Shaft Type
Hollow shaft
Electrical connection
Cable
Technology
Optical
Flange type
Flange with mounting element
Protection class shaft
IP65
Output type
Incremental
Resolution, incremental
2048 ppr
Encoder line
Industrial-Line
Housing material
Die-cast zinc
Protection class
IP65
Shaft diameter D [mm]
38 mm
Operating voltage
5…30 VDC
Output function
Push-Pull 7272, with inverted signals
Ambient Temperature
-40 degrees celsius, 80 degrees celsius
Operating Voltage
30 volts

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of RI-43H38S8-2F2048-C1M on Powermatic Associates is $630.00. Order now.

About the product

Incremental Hollow Shaft Encoder, Industrial Line, Resolution, incremental 2048 ppr, Incremental Hollow Shaft Encoder, Protection class IP65 on the shaft side, ‐40 ... +80°C, max. 6000 rev / min, 5…30 VDC, Cable connection, 8-pole, Push-pull, with inverted signals, Pulse frequency max. 300 kHz, 2048 pulses per revolution
