RU200-CP40-LIU2P8X2T/S10 Turck Industrial Automation Components

Name: RU200-CP40-LIU2P8X2T/S10
Brand: Turck
Price: 480.3 USD
Availability: BackOrder

RU200-CP40-LIU2P8X2T/S10 on Powermatic Associates

Part#:RU200-CP40-LIU2P8X2T/S10

Alt. Part#:1610093

Manufacturer:Turck

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

RU200-CP40-LIU2P8X2T/S10 Turck - RU200-CP40-LIU2P8X2T/S10 Ultrasonic Sensor, Diffuse Mode Sensor

Product Details

Weight
213 g
RoHS
Yes
Country Of Origin
DEU
HTS Code
8536507000
Range
50…2000 mm
Output function
PNP
Radiation direction
straight
Protection class
IP40
Design
Rectangular
Switching element function
NO/NC
Housing quality
PBT-GF30-V0
Construction size
166 x 40 x 40 mm, CP40
Electrical connection
Terminal chamber, Terminal box with cable gland
Operating voltage
15…30 VDC
Ambient temperature
0…+70 °C
Function
Proximity
Voltage output
0…10 V
Current output
4…20 mA
Special features
Pushbutton
Housing material
Plastic

Weight

213 grams

Country of Origin

Germany

Operating Voltage

15 volts, 30 volts

Ambient Temperature

70 degrees celsius

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of RU200-CP40-LIU2P8X2T/S10 on Powermatic Associates is $480.30. Order now.

About the product

Ultrasonic Sensor, Diffuse Mode Sensor, Max. range 2000 mm, Separate transducers for transmitter and receiver, Rectangular housing 40 x 40 x 166 mm, Connection via screw terminals, Terminal chamber for cable gland NPT, Teach range adjustable via button, Blind zone: 5 cm, Range: 200 cm, Resolution: 1 mm, Aperture angle of sonic cone: ±60 °, 1 × switching output, PNP, NO/NC programmable, 1 × analog output 4…20 mA/0…10 V
