731-638 WAGO Industrial Automation Components

WAGO 731-638 is a connector part of the MCS - MULTI CONNECTION SYSTEM, designed without breaking capacity as per DIN EN 61984, indicating it should not be connected or disconnected under load or when live. It adheres to IEC/EN 60664-1 standards, with nominal voltages of 500V (III/3), 630V (III/2), and 1000V (II/2), all with a rated impulse voltage of 6kV and a rated current of 12A. UL and CSA approvals include ratings of 300V and 600V with currents of 15A and 10A depending on the use group. The connector features 8 connection points, supports a single connection type across one level, and utilizes CAGE CLAMP technology for connection, compatible with solid and fine-stranded conductors ranging from 0.08 to 2.5mm2. It has a pin spacing of 7.62mm, dimensions of 61.62mm in width, 14.3mm in height, and 27.5mm in depth, and includes variable coding and anti-rotation protection. The male connector/plug is made from Polyamide (PA66) in orange, with a chrome-nickel spring steel clamping spring, electrolytic copper contacts with tin plating, and meets UL94 V0 flammability standards. It operates within a temperature range of -60 to +100°C, weighs 14.2g, and is RoHS compliant without exemptions. The product is packaged in boxes of 25 pieces, with a GTIN of 4044918268226 and a customs tariff number of 85366930000, indicating its origin in Germany.
