735-122 WAGO Industrial Automation Components
Part#:735-122
Manufacturer:WAGO
Category:Industrial Automation Components
Product Lifecycle:Active
Product description
735-122 WAGO - PCB terminal block; push-button; 1.5 mm²; Pin spacing 3.81 mm; 2-pole; PUSH WIRE®; 1,50 mm²; orange
Product Details
- Weight 1.611000424 g
- Country Of Origin Switzerland
- HTS Code 85369010000
- Current 10 amperes, 10 amperes
- Insulation Material Polyamide
- Contact Type Tin
- Voltage 250 volts, 300 volts
- Color Orange
- Strip Length 0.35 inches, 9 millimeters
- Flammability Class V0
- Depth 0.425 inches, 10.8 millimeters
- Actuator Push-button
- Package Type Box
- Conductor Size 1.5 millimeters, 16 american wire gauge
- Width 0.3 inches, 7.62 millimeters
- Contact Material Copper
- Weight 1.611 grams
- Height 0.862 inches, 21.9 millimeters
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 735-122 on Powermatic Associates is $0.81. Order now.
About the product
WAGO 735-122 is an automation part with a short circuit breaking rating and electrical data adhering to IEC/EN 60664-1 standards, including nominal voltages of 250V (III/3), 320V (III/2), and 630V (II/2), with rated impulse and surge voltages of 4kV across different overvoltage categories and pollution degrees. It has a rated current of 10A. UL and CSA approvals are present, with rated voltages of 300V and rated currents of 10A for both UL and CSA in Use Groups B and D. The part features 2 connection points, supports a single connection type across one level, and utilizes PUSH WIRE connection technology with push-button actuation. It accommodates solid conductors of 0.5...1.5mm2 / 20...16 AWG, fine-stranded conductors with or without insulated ferrules of 0.5...1mm2, and specifies a strip length of 8...9mm / 0.31...0.35". The conductor connection direction to PCB is 90 degrees, with a pole number of 2. Physical specifications include a pin spacing of 3.81mm / 0.15", dimensions of 7.62mm width, 21.9mm height, 18.4mm height from the surface, and 10.8mm depth. Solder pin length is 3.5mm with dimensions of 0.4 x 0.9mm and a drilled hole diameter with tolerance of 1 (+0.1)mm. It features a THT PCB contact, in-line solder pin arrangement, and 2 solder pins per potential. The part is orange, made from Polyamide (PA66) with a flammability class of V0, and uses Chrome-Nickel spring steel (CrNi) for the clamping spring and Electrolytic Copper (ECu) with tin plating for contacts. It has a fire load of 0.021MJ and weighs 1.6g. The operational temperature range is -60...+105°C. It is categorized under Product Group 4 (Printed Circuit Connectors), with compliance to RoHS, and comes in a box packaging of 660 (165) pcs per box. The country of origin is CH, with a GTIN of 4044918792561 and a customs tariff number of 85369010000.
