03036ET3ER286TSC-W22 WEG AC Motors
Product Details
- Number of Poles 2 Pole
- Voltage 230/460 V
- Output Rating 30 HP
- Rated Speed 3545 rpm
- Flange Type C
- L. R. Amperes 431/216 A
- Locked rotor time 27s (cold) 15s (hot)
- Altitude 1000 m.a.s.l.
- Slip 1.53 %
- LRC 6.3x(Code G)
- Temperature rise 80 K
- Standard NEMA MG-1
- Output 30 HP (22 kW)
- Design B
- Rotation¹ Both (CW and CCW)
- Rated speed 3545 rpm
- Moment of inertia (J) 3.37 sq.ft.lb
- Ambient temperature -20°C to +40°C
- Output rating 30 HP
- Number of Poles 2
- Locked rotor torque 200 %
- Duty Cycle Cont.(S1)
- No load current 18.2/9.10 A
- Degree of Protection IP55
- Voltage 230/460//380 V
- Rated voltage 230/460 V
- Service factor 1.25
- Noise level² 72.0 dB(A)
- Frame 286TSC
- Rated torque 44.4 ft.lb
- Approx. weight³ 388 lb
- Enclosure IC411 - TEFC
- Rated current 68.4/34.2 A
- Insulation Class F
- Mounting W-6
- Terminal box¹ Left position
- Frequency 60 Hz
- Breakdown torque 250 %
- Starting Method Direct On Line
- Synchronous speed 3600 rpm
- Number of poles 2
- Flange C
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
