Q40RW3FF400 Banner Proximity Sensors

Q40RW3FF400 on Powermatic Associates
Banner

Part#:Q40RW3FF400

Alt. Part#:33383

Manufacturer:Banner

Category:Proximity Sensors

Product Lifecycle:Active

Product description

EZ-BEAM Q40 Series: Fixed Field; Range: 400 mm; Input: 20-250 V ac; Output: SPST Solid-state Dark Operate; 2 m (6.5 ft) Cable

Product Details

  • Weight
    250.382784 g
  • Country Of Origin
    US
  • Wavelength
    880 nm
  • Material
    thermoplastic housing
  • Primary brand
    Banner Engineering
  • Supply voltage (AC)
    20Vac-250Vac (200Vac / 220Vac / 240Vac nom.)
  • Main function
    Sensor (Photo-electric)
  • Design
    background suppression system
  • Thread size
    M30
  • Degree of protection
    IP67 NEMA 6P
  • Product series / family name
    EZ-BEAM series
  • Functions
    Fixed-field photo-electric sensor green LED (power ON) amber LED (output state)
  • Sub-range name
    Q40 AC series
  • Sensing distance
    400mm
  • Light Color
    Infrared (IR)
  • Response time
    16ms / 0.016 s
  • Order code / Manufacturer SKU
    33383
  • Operating mode
    Dark-ON
  • Shape
    Rectangular
  • Ambient air temperature for operation
    -40...+70 °C
  • Connection type
    Pre-wired with 6.5ft / 2m cable terminated with bare end flying leads
  • Digital outputs
    1 x digital output (Solid-state AC output; SPST contact type)
  • Compliant with standard(s)
    cULus CCC cCSAus CE
  • Cable Length (m)
    2
  • Sensing Mode (Detailed)
    Background Suppression (Fixed)
  • Input/Output
    Solid-State AC Switch
  • Max Sensing Distance (mm)
    400
  • Primary Housing Material
    Thermoplastic
  • Sensing Mode (General)
    Proximity
  • Power
    AC
  • Connection
    Cable
  • Housing Style
    Rectangular
  • Min Op. Temp. (°C)
    -40
  • Power Supply/Supply Voltage
    20-250 V ac
  • Operation
    Dark Operate
  • Sensing Beam
    Infrared LED
  • Quick Disconnect Type
    No QD
  • Outputs
    Solid-State AC Switch
  • Max Op. Temp. (°C)
    70
  • Output response time (ms)
    16
  • Special Feature: Intrinsically Safe
    No
  • Repeatability (µs)
    4000
  • Number of Pins
    3
  • Special Feature: Water Detection
    No
  • Lens Material
    Polycarbonate
  • Barrel Diameter (mm)
    30
  • Max Op. Relative Humidity [%]
    90% @ 50°C
  • Feature: Audible
    No
  • IP Rating
    IP67
  • Feature: Encapsulated
    Yes
  • Special Feature: Remote Teach
    No
  • Feature: Ecolab Certified
    Yes
  • IO Link
    No
  • Adjustments
    N/A
  • Feature: Chemical Resistant
    No
  • NEMA Rating
    NEMA 6P
  • Feature: Hazardous Area
    No
  • DeviceNet
    No
  • Indicator
    LEDs
  • Opposed Mode Emitter/Receiver
    N/A
  • Delay at Power-up (ms)
    100
  • Feature: Timing (Hold/Delay)
    No

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of Q40RW3FF400 on Powermatic Associates is $186.00. Order now.


About the product

Banner Engineering Q40RW3FF400 is a fixed-field photo-electric sensor designed with a background suppression system and an M30 threaded mount for secure installation. This sensor operates within an ambient air temperature range of -40 to +70°C and is housed in a durable thermoplastic material. It features a pre-wired 6.5ft / 2m cable with bare end flying leads for connection and is powered by a supply voltage ranging from 20Vac to 250Vac, with nominal values at 200Vac, 220Vac, and 240Vac. Part of the Q40 AC series, it offers a sensing distance of 400mm and utilizes infrared light with a wavelength of 880 nm. The Q40RW3FF400 operates in Dark-ON mode and includes one digital output (Solid-state AC output; SPST contact type) with a response time of 16ms / 0.016 s. It is designed to provide a degree of protection rated at IP67 NEMA 6P, ensuring its operation in challenging environments.
