Q45XB6DLQ Banner Proximity Sensors
Part#:Q45XB6DLQ
Alt. Part#:37884
Manufacturer:Banner
Category:Proximity Sensors
Product Lifecycle:Active
Product description
Q45X Series: Diffuse; Range: 1.8 m; Input: depends on Bus Card; Output: depends on Bus Card used; 5-pin Mini Integral QD
Product Details
- Weight 244.93968 g
- Country Of Origin US
- Sensing distance 1.8m
- Primary brand Banner Engineering
- Connection type Pre-equipped with 5-pin 7/8" Mini connector
- Compliant with standard(s) cCSAus
- Main function Sensor (Photo-electric)
- Sub-range name Q45X
- Shape Rectangular
- Thread size M30
- Product series / family name Q series
- Supply voltage (DC) 10Vdc-30Vdc (12Vdc / 24Vdc nom.)
- Wavelength 880 nm
- Response time 2ms / 0.002 s
- Ambient air temperature for operation -40...+70 °C
- Functions Photo-electric sensor green LED (power ON) red LED (signal) yellow LED (output state) potentiometer adjustment
- Mounting mode Threaded mount
- Design diffuse mode
- Light Color Infrared (IR)
- Operating mode Light-ON Dark-ON
- Material thermoplastic housing Acrylic lns.
- Digital outputs 1 x digital output (PNP/NPN transistor)
- Order code / Manufacturer SKU 37884
- Degree of protection IP67 NEMA 6P
- Sensing Beam Infrared LED
- Max Op. Temp. (°C) 70
- Number of Pins 5
- Opposed Mode Emitter/Receiver N/A
- Input/Output Discrete
- Special Feature: Remote Teach No
- IP Rating IP67
- Feature: Audible No
- Special Feature: Water Detection No
- Connection Integral QD
- Adjustments Potentiometer
- Feature: Chemical Resistant No
- Sensing Mode (Detailed) Diffuse
- Output response time (ms) 2
- Max Op. Relative Humidity [%] 90% @ 50°C
- Max Sensing Distance (mm) 1800
- Power Supply/Supply Voltage 10-30 V dc
- Delay at Power-up (ms) 100
- Feature: Timing (Hold/Delay) No
- Primary Housing Material Thermoplastic
- Operation Light/Dark Operate
- Sensing Beam Wavelength 880
- Barrel Diameter (mm) 30
- Housing Style Rectangular
- Outputs Bipolar (NPN & PNP)
- NEMA Rating NEMA 6P
- Feature: Hazardous Area No
- Sensing Mode (General) Proximity
- Min Op. Temp. (°C) -40
- Special Feature: Intrinsically Safe No
- Lens Material Acrylic
- IO Link No
- Power DC
- Repeatability (µs) 500
- DeviceNet No
- Indicator LEDs
- Quick Disconnect Type 7/8 in. (Mini)
- Feature: Encapsulated No
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of Q45XB6DLQ on Powermatic Associates is $152.00. Order now.
About the product
Banner Engineering Q45XB6DLQ is a photo-electric sensor designed for versatile applications, featuring a diffuse mode with potentiometer adjustment. It comes with an M30 threaded mount for secure installation and operates within an ambient air temperature range of -40 to +70°C. This sensor is equipped with a 5-pin 7/8" mini connector for easy connection and falls under the Q45X series. It boasts an IP67 NEMA 6P degree of protection, ensuring durability in various environments. The supply voltage requirement ranges from 10Vdc to 30Vdc, with 12Vdc and 24Vdc as nominal values. The Q45XB6DLQ has a rectangular shape with a thermoplastic housing and an acrylic lens, designed for a sensing distance of up to 1.8m. It utilizes infrared light with a wavelength of 880 nm and supports both Light-ON and Dark-ON operating modes. Additionally, it features a digital output (PNP/NPN transistor) and a quick response time of 2ms / 0.002 s.
