S22LGRYP Banner Pick-to-Light Sensors

Name: S22LGRYP
Brand: Banner
Price: 44 USD
Availability: BackOrder

Part#:S22LGRYP

Alt. Part#:86099

Manufacturer:Banner

Category:Pick-to-Light Sensors

Product Lifecycle:Active

Product description

S22 EZ Light - 22 mm - IP67; Three Color: Green Red Yellow; 10-30 V dc PNP Input; 4-wire 2 m Cable

Product Details

Weight
81.64656 g
Country Of Origin
CN
Multi-Color Device
Single Color On
Modbus RTU
No
Pro-Editor Compatible (Discrete)
No
Wireless
No
IO Link
No
Feature: Chemical Resistant
No
Feature: Audible
No
Feature: Hazardous Area
No
Physical Dimensions (LxWxH or DxH mm)
26.0 x 35.3
Max Op. Temperature (°C)
50
Feature: Washdown Rated
Yes
Primary Housing Color
Black
Primary Window Material
Polycarbonate Diffused
Min Op. Temperature (°C)
-40
Max Input Response Time (ms)
1
Supply Voltage
10-30 V dc
Environmental Rating
IP67; IP69
Input Type
PNP

Lumens Color 3

0.80

Color Option 3

Yellow

NEMA Type and UL Type Rating

NEMA and UL 4X, 13

Max Current Color (mA)

Color 3 - Wavelength/Color Temp/Coordinates

590 nm

Number of Input Pins/Conductors

Color 1 - Wavelength/Color Temp/Coordinates

525 nm

Lumens Color 2

1.1

Color 2 - Wavelength/Color Temp/Coordinates

625 nm

Color Option 2

Red

Color Technology

Standard LED

Animation Option 1

Solid On

Connection

Cable

Color Option 1

Green

Lumens Color 1

4.1

Product Size (mm)

Power

Housing Style

Barrel Mount - Flat Window

Power Source

Primary Housing Material

Polycarbonate

Mounting Thread

M22 x 1.5

Color Input Control

Individual (One wire/color, same number of colors as input wires)

Number of Colors / Segments

Indication

Yes

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of S22LGRYP on Powermatic Associates is $44.00. Order now.

About the product

Banner Engineering S22LGRYP is a pilot light from the EZ-LIGHT series, featuring a 3-color G/R/Y color pattern LED illumination designed for use as an LED pilot light indicator. It is constructed with a polycarbonate (PC) diffused window and a polycarbonate (PC) base, ensuring durability. This part has a 22mm indicator diameter and comes pre-wired with a 2m / 6.5ft 4-wire cable terminated with bare end flying leads for easy installation. The housing is black, and it operates on a supply voltage of 10Vdc-30Vdc (12Vdc-24Vdc nom.). It is designed for flush mounting in a 22mm hole with an M22 thread. The S22LGRYP can operate in ambient air temperatures ranging from -40°C to +50°C and offers a high degree of protection with ratings of IP67, IP69K, NEMA 4X, NEMA 13, UL type 4X, and UL type 13. Its flat window and threaded cylindrical barrel shape are designed for straightforward installation, and it has a current consumption of 25mA. Additionally, it features 3 x digital inputs (10-30Vdc; PNP) for color control.
