TTR558RPSA6C-2.0FL-CTR Banner Safety Light Curtains
Part#:TTR558RPSA6C-2.0FL-CTR
Alt. Part#:810325
Manufacturer:Banner
Category:Safety Light Curtains
Product Lifecycle:Active
Product description
TTR Series 6 Beam Sensor Array Diffuse; Resolution: 54 mm; Range: 120 mm; Input 18-30 V dc; Output: DO PNP; 2 m (6.5 ft) Cable Flying Leads
Product Details
- Weight 344.72992 g
- Country Of Origin MX
- End Cap Type C: Adj Hex / Spring 11 mm Hex - 8 mm Round
- Connection Cable
- Output response time (ms) 1
- IP Rating IP50
- Quick Disconnect Type No QD
- Delay at Power-up (ms) 1500
- Cable Length (m) 2
- Special Feature: Remote Teach No
- Slot Depth/Array Length (mm) 558
- Housing Style Sensing Array Bar
- Lens Material Polycarbonate
- Distance to First Beam [mm] 144
- Sensing Mode (Detailed) Diffuse
- Number of Pins 4
- Operation Dark Operate
- Power DC
- Adjustments N/A
- Indicator Indicator LEDs
- Slot Overall Depth (mm) 19
- Max Op. Temperature (°C) 55
- Beam to Beam Spacing [mm] 54
- Primary Housing Material Black Anodized Aluminum
- Max Sensing Range (mm) 120
- Min Op. Temperature (°C) -10
- Number of Beams 6
- Outputs PNP
- Max Op. Relative Humidity (%) 95% @ 55°C
- Power Supply/Supply Voltage 18-30 V dc
- NEMA Rating N/A
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of TTR558RPSA6C-2.0FL-CTR on Powermatic Associates is $241.00. Order now.
About the product
Banner Engineering TTR558RPSA6C-2.0FL-CTR is a sensor array designed with a diffuse mode featuring 6 beams. This part is pre-wired with a 2-meter cable that has bare end flying leads for connection. It has a rectangular shape with dimensions including a 558mm array length and a beam spacing/pitch of 54mm. The supply voltage required for operation ranges from 18Vdc to 30Vdc, with a nominal voltage of 24Vdc. It is capable of operating within an ambient air temperature range of -10 to +70 degrees Celsius. The sensor offers a degree of protection rated at IP50. It includes 1 x digital output (PNP transistor) and has a sensing distance of 120mm. The light emitted by the sensor is in the infrared (IR) spectrum with a wavelength of 940 nm.
