VSM-2S4AND100-Q3 Banner Proximity Sensors
Part#:VSM-2S4AND100-Q3
Alt. Part#:806913
Manufacturer:Banner
Category:Proximity Sensors
Product Lifecycle:Active
Product description
VSM-2 Series: 4 mm Smooth Barrel Diffuse; Range: 100 mm; Input 10-30 V dc; Output: 1 NPN; LO (Light Operate); 4-pin M8 Pigtail QD
Product Details
- Weight 19.958048 g
- Sensing Mode (Detailed) Diffuse
- Min Op. Temp. (°C) -25
- Special Feature: Intrinsically Safe No
- Indicator LEDs
- Feature: Encapsulated No
- Sensing Beam Visible Red LED
- Max Sensing Distance (mm) 100
- Power Supply/Supply Voltage 10-30 V dc
- IP Rating IP67
- Feature: Hazardous Area No
- Sensing Mode (General) Proximity
- Output response time (ms) 0.5
- Adjustments N/A
- Power DC
- Special Feature: Remote Teach Yes
- Opposed Mode Emitter/Receiver N/A
- Housing Style Barrel - Smooth
- Outputs NPN
- Repeatability (µs) 1000
- DeviceNet No
- IO Link No
- Primary Housing Material Stainless Steel
- Operation Light Operate
- Delay at Power-up (ms) 20
- Feature: Chemical Resistant Yes
- Input/Output Discrete
- Special Feature: Water Detection No
- Feature: Timing (Hold/Delay) No
- Small Visible Spot LED
- Connection Pigtail QD
- Max Op. Temp. (°C) 65
- Lens Material PMMA
- Feature: Audible No
- Cable Length (m) 0.15
- Quick Disconnect Type M8 (Pico)
- Number of Pins 4
- Barrel Diameter (mm) 4
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of VSM-2S4AND100-Q3 on Powermatic Associates is $230.00. Order now.
About the product
Banner Engineering VSM-2S4AND100-Q3 is a photo-electric sensor with a stainless steel housing, P.B.T./Polymethyl methacrylate (PMMA) optics, and a Polyurethane (PUR) cable sheath. It offers an IP67 degree of protection, making it suitable for operation in ambient air temperatures ranging from -25 to +65 °C. This sensor operates in Light-ON mode and features 1 x digital output (NPN transistor; 100mA) with a response time of 500µs / 0.0005 s. It comes pre-wired with a 6" / 15cm PUR cable terminated with a 3-pin Pico-style M8 connector. The sensor has a 4mm diameter, cylindrical smooth shape, and emits a visible red light with a wavelength of 630 nm. It operates on a supply voltage of 10Vdc-30Vdc (12Vdc / 24Vdc nom.) and is designed in diffuse mode with a sensing distance of 0...100mm. This part belongs to the VSM-2 series.
