VSM-2S4NAEL-Q7 Banner Proximity Sensors
Part#:VSM-2S4NAEL-Q7
Alt. Part#:806807
Manufacturer:Banner
Category:Proximity Sensors
Product Lifecycle:Active
Product description
VSM-2 Series: 4 mm Smooth Barrel Emitter; Range: 500 mm; Input 10-30 V dc; Output: No Output; Integral 3-pin M8
Product Details
- Weight 14.061352 g
- Country Of Origin LK
- Sensing Mode (Detailed) Emitter
- Special Feature: Intrinsically Safe No
- NEMA Rating N/A
- Feature: Audible No
- Power Supply/Supply Voltage 10-30 V dc
- Max Op. Temp. (°C) 65
- Number of Pins 3
- Feature: Chemical Resistant Yes
- Primary Housing Material Stainless Steel
- Operation N/A
- Special Feature: Water Detection No
- Outputs N/A
- Output response time (ms) 0.5
- Lens Material PMMA
- Feature: Timing (Hold/Delay) No
- Feature: Encapsulated No
- Quick Disconnect Type M8 (Pico)
- Special Feature: Remote Teach No
- Indicator LEDs
- Max Sensing Distance (mm) 500
- Housing Style Barrel - Smooth
- IP Rating IP67
- Feature: Hazardous Area No
- Power DC
- Sensing Beam Visible Red LED
- Min Op. Temp. (°C) -25
- Adjustments N/A
- DeviceNet No
- Sensing Mode (General) Opposed
- Connection Integral QD
- Delay at Power-up (ms) 20
- Opposed Mode Emitter/Receiver Emitter
- Small Visible Spot LED
- Repeatability (µs) 1000
- Barrel Diameter (mm) 4
- IO Link No
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of VSM-2S4NAEL-Q7 on Powermatic Associates is $87.00. Order now.
About the product
Banner Engineering VSM-2S4NAEL-Q7 is a photo-electric sensor with a stainless steel housing and P.B.T./Polymethyl methacrylate (PMMA) optics. It offers an IP67 degree of protection, making it suitable for operation in ambient air temperatures ranging from -25 to +65°C. This sensor features a response time of 500µs / 0.0005 s and is equipped with a 3-pin Pico-style QD M8 connector for connectivity. With a 4mm diameter and cylindrical smooth shape, it operates on a 630 nm visible red wavelength. The VSM-2S4NAEL-Q7 is designed for a through-beam system / opposed mode and has a sensing distance of 0 to 500mm. It operates on a supply voltage of 10Vdc-30Vdc (12Vdc / 24Vdc nom.) and is part of the VSM-2 series, functioning as a photo-electric sensor (emitter alone).
