153431 Festo Pneumatic Fittings
Part#:153431
Alt. Part#:QSKL-1/4-6
Manufacturer:Festo
Category:Pneumatic Fittings
Product Lifecycle:Active
Product description
self-sealing push-in L-fitting QSKL-1/4-6 360° orientable, male thread with external hexagon. Size: Standard, Nominal size: 3,2 mm, Approved tubing type: (* PAN-, * PAN-MF-, * PAN-R-, * PAN-V0-, * PEN-, * PFAN-, * PLN-, * PTFEN-, * PUN-, * PUN-CM-, * PUN-
Product Details
- Size Standard
- Approved tubing type PAN- PUN-V0-
- Pack size 1
- Temperature-dependent operating pressure -0.95 bar ... 14 bar
- Ambient temperature -10 °C ... 80 °C
- Note on materials RoHS-compliant
- Nominal width 3.2 mm
- Releasing ring color Blue
- Tubing insertion depth 13.5 mm
- Design Push-pull principle
- Max. tightening torque 12 Nm
- Material of tube retaining claw High-alloy stainless steel
- Maritime classification See certificate
- Mounting position Any
- Corrosion resistance class (CRC) 1 - Low corrosion stress
- Pneumatic connection 2 for pneumatic tubing outside diameter 6 mm
- Releasing ring material POM
- Type code QSKL
- Operating pressure for entire temperature range -0.95 bar ... 6 bar
- Information on operating and pilot media Operation with oil lubrication possible
- Product weight 29.5 g
- Material of tubing seal NBR
- Type of seal on screwed trunnion Coating
- Operating medium Compressed air as per ISO 8573-1:2010 [7:-:-]
- Pneumatic connection 1 External thread R1/4
- Housing material PBT
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
