8903SMO2V04 Schneider Electric Electronic Components

8903SMO2V04 on Powermatic Associates
Schneider Electric

Part#:8903SMO2V04

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

Lighting contactor, electrically held, 30 A, 3 pole, open, 277V 60Hz

Product Details

  • Control Units
    No control units
  • Depth
    4.21 in (107 mm)
  • Current Rating
    30 A
  • Electrical Connection
    Lugs
  • Auxiliary Contacts
    Without
  • Width
    3.23 in (82 mm)
  • Other Options
    None
  • Product
    Electrically Held Lighting Contactor
  • Control Circuit Voltage
    277 V AC 60 Hz
  • Type
    S
  • Pilot Light
    Without pilot light
  • Number Of Poles
    3P
  • Height
    3.50 in (89 mm)

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 8903SMO2V04 on Powermatic Associates is $489.00. Order now.

8903SMO2V04 Related Documents

Product Datasheet-1631037577945.pdfInstruction Sheet-1631037577942.pdfCatalog-1631037577947.pdf
