BGF26045 Schneider Electric Electronic Components

BGF26045 on Powermatic Associates
Schneider Electric

Part#:BGF26045

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric BGF26045 is a Moulded Case Circuit Breaker (MCCB) within the PowerPacT BGF sub-range, featuring a PowerPact B-Frame 100 TMD 2P-2t design with a rated current of 45A and a rated voltage of 600Vac 600Y/347Vac. It has a rated impulse voltage (Uimp) of 8 kV and offers a connection via a Term. nut kit for fixed busbar connection on both line and load sides. The device is IP40 protected, has a mechanical durability of 15,000 operations, and can be mounted either on a DIN rail or as an individual unit on a plate. It is a 2-pole (2P) circuit breaker with dimensions of 137 mm in height, 80 mm in depth, and 54 mm in width. The BGF26045 operates in Utilisation category A and features over-current protection fixed at 45A, short-circuit hold current fixed at 400A, and short-circuit trip current fixed at 600A. It has a rated insulation voltage (Ui) of 800 V, a rated operating voltage (Ue) of 525 V, and offers thermal and magnetic protection functions. The trip current rating is 45 AT, with an electrical durability of 10,000 operations at 440Vac. The frame current rating is 100 AF, and it operates via a toggle (manual) mode. Its short circuit breaking rating includes 65kA at 240Vac, 35kA at 480Vac, 35kA at 480Y/277Vac, and 18kA at 600Y/347Vac under UL489 standards. The trip unit type is Thermal-Magnetic (fixed) with no display.

Product Details

  • Line Rated Current
    45 A
  • Trip Unit Technology
    Thermal-magnetic
  • Product Name
    PowerPact B
  • Connection Pitch
    1.06 in (27 mm)
  • Depth
    3.15 in (80 mm)
  • Device Short Name
    BG 045
  • Trip Unit Name
    TM-D
  • [Ue] Rated Operational Voltage
    525 V AC 50/60 Hz UL 489
  • Local Signalling
    for presence of auxiliary contacts flag (green)
  • Number Of Poles
    2P
  • Device Application
    Distribution
  • Suitability For Isolation
    Yes conforming to IEC 60947-2
  • Color
    Gray RAL 7016)
  • Quantity Per Set
    Set of 1
  • Power Wire Stripping Length
    0.79 in (20 mm)
  • Range
    PowerPact
  • [Uimp] Rated Impulse Withstand Voltage
    8 kV IEC 60947-2
  • Utilisation Category
    Category A
  • Net Weight
    1.47 lb(US) (0.669 kg)
  • Continuous Current Rating
    80 %
  • Mechanical Durability
    15000 cycles IEC 947-1 Annex K ed 5.2
  • Height
    5.39 in (137 mm)
  • Breaking Capacity Code
    G
  • Electrical Durability
    10000 cycles IEC 947-1 Annex K ed 5.2 440 V In
  • 9 Mm Pitches
    6
  • Protected Poles Description
    2t
  • Product Or Component Type
    Circuit breaker
  • [Ui] Rated Insulation Voltage
    800 V IEC 60947-2
  • Width
    2.13 in (54 mm)
  • Control Type
    Toggle
  • Electrical Connection
    Terminal nut ON and OFF end
  • AWG Gauge
    AWG 14...AWG 8 aluminium/copper AWG 6...AWG 3/0 aluminium/copper
  • Mounting Mode
    Clip-on 35 mm symmetrical DIN rail) By screws plate)
  • Number Of Slots
    1 auxiliary switch OF plug-in) 1 voltage release MN or MX plug-in)
  • Tightening Torque
    44.25 lbf.in (5 N.m) 0.00…0.02 in² (2.5…16 mm²) (AWG 14...AWG 4) 79.66 lbf.in (9 N.m) 0.04…0.15 in² (25…95 mm²) (AWG 3...AWG 3/0)
  • [Ics] Rated Service Breaking Capacity
    65 kA 220...240 V AC 50/60 Hz IEC 60947-2 18 kA 500...525 V AC 50/60 Hz IEC 60947-2 35 kA 380...415 V AC 50/60 Hz IEC 60947-2 35 kA 440 V AC 50/60 Hz IEC 60947-2
  • Breaking Capacity
    65 kA 208Y/120 V AC 50/60 Hz UL 489 65 kA 240 V AC 50/60 Hz UL 489 35 kA 480/277 V AC 50/60 Hz UL 489 35 kA 480 V AC 50/60 Hz UL 489 20 kA 250 V DC UL 489 18 kA 600Y/347 V AC 50/60 Hz UL 489

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of BGF26045 on Powermatic Associates is $1,142.00. Order now.

BGF26045 Related Documents

Product Datasheet-1631033670545.pdfCatalog-1631033670542.pdfInstruction Sheet-1631033670549.pdf
