BGF46110 Schneider Electric Electronic Components

BGF46110 on Powermatic Associates
Schneider Electric

Part#:BGF46110

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric BGF46110 is a Moulded Case Circuit Breaker (MCCB) within the PowerPacT BGF sub-range, featuring a PowerPact B-Frame 125 TMD with 4 poles (4P) and a terminal nut kit for fixed busbar connection on both line and load sides. It has a rated current of 110A, with a rated voltage for AC at 600Vac 600Y/347Vac and for DC at 250Vdc. The rated impulse voltage (Uimp) is 8 kV, and it offers a degree of protection of IP40. This MCCB has a mechanical durability of 15,000 operations at no load and an electrical durability of 10,000 operations with load (440Vac; In). It is designed for fixed mounting on a DIN rail or as an individual unit mount on a plate. The protection settings include over-current fixed at 110A, short-circuit hold current fixed at 1000A, and short-circuit trip current fixed at 1500A. It features thermal protection for overload and magnetic protection for short-circuits, with a trip current rating of 110 AT. The rated insulation voltage (Ui) is 800 V, with a rated operating voltage (Ue) of 525 V. The frame current rating is 125 AF, and it operates with a toggle (manual) mode. The short circuit breaking rating varies by voltage, with 65kA at 240Vac, 35kA at 480Vac and 480Y/277Vac, and 18kA at 600Y/347Vac under UL489 standards. The trip unit type is thermal-magnetic (fixed) without a display.

Product Details

  • Number Of Poles
    4P
  • Trip Unit Name
    TM-D
  • Mechanical Durability
    15000 cycles IEC 947-1 Annex K ed 5.2
  • Product Name
    PowerPact B
  • Protected Poles Description
    4t
  • Breaking Capacity Code
    G
  • [Ui] Rated Insulation Voltage
    800 V IEC 60947-2
  • Product Or Component Type
    Circuit breaker
  • Suitability For Isolation
    Yes conforming to IEC 60947-2
  • Quantity Per Set
    Set of 1
  • 9 Mm Pitches
    12
  • Control Type
    Toggle
  • Device Short Name
    BG 110
  • Utilisation Category
    Category A
  • Line Rated Current
    110 A
  • [Uimp] Rated Impulse Withstand Voltage
    8 kV IEC 60947-2
  • Connection Pitch
    1.06 in (27 mm)
  • Height
    5.39 in (137 mm)
  • Device Application
    Distribution
  • Trip Unit Technology
    Thermal-magnetic
  • [Ue] Rated Operational Voltage
    525 V AC 50/60 Hz UL 489
  • Continuous Current Rating
    80 %
  • Local Signalling
    for presence of auxiliary contacts flag (green)
  • Range
    PowerPact
  • Color
    Grey (RAL 7016)
  • Depth
    3.15 in (80 mm)
  • Net Weight
    2.74 lb(US) (1.241 kg)
  • Electrical Durability
    10000 cycles IEC 947-1 Annex K ed 5.2 440 V In
  • Electrical Connection
    Terminal nut ON and OFF end
  • Width
    4.25 in (108 mm)
  • Power Wire Stripping Length
    0.79 in (20 mm)
  • Mounting Mode
    Clip-on 35 mm symmetrical DIN rail) By screws plate)
  • AWG Gauge
    AWG 14...AWG 8 aluminium/copper AWG 6...AWG 3/0 aluminium/copper
  • Tightening Torque
    44.25 lbf.in (5 N.m) 0.00…0.02 in² (2.5…16 mm²) (AWG 14...AWG 4) 79.66 lbf.in (9 N.m) 0.04…0.15 in² (25…95 mm²) (AWG 3...AWG 3/0)
  • Number Of Slots
    1 auxiliary switch OF plug-in) 1 voltage release MN or MX plug-in) 1 alarm switch SD plug-in)
  • [Ics] Rated Service Breaking Capacity
    65 kA 220...240 V AC 50/60 Hz IEC 60947-2 18 kA 500...525 V AC 50/60 Hz IEC 60947-2 35 kA 380...415 V AC 50/60 Hz IEC 60947-2 35 kA 440 V AC 50/60 Hz IEC 60947-2
  • Breaking Capacity
    65 kA 208Y/120 V AC 50/60 Hz UL 489 65 kA 240 V AC 50/60 Hz UL 489 35 kA 480/277 V AC 50/60 Hz UL 489 35 kA 480 V AC 50/60 Hz UL 489 20 kA 250 V DC UL 489 18 kA 600Y/347 V AC 50/60 Hz UL 489

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

BGF46110 Related Documents

Catalog-1631034251431.pdfInstruction Sheet-1631034251435.pdfProduct Datasheet-1631034251437.pdf
