EGB34080CA Schneider Electric Electronic Components

EGB34080CA on Powermatic Associates
Schneider Electric

Part#:EGB34080CA

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

E-Frame Brkr 80A, 3P, 480Y/277V, 35/65kA, Bolt-on Mnt

Product Details

  • Trip Unit Rating
    2300 A
  • Local Signalling
    Trip indicator
  • Trip Unit Technology
    Thermal-magnetic
  • Module Type
    E-Frame
  • Height
    5.66 in (143.76 mm)
  • Product Destination
    NF panelboard
  • Product Or Component Type
    Miniature circuit-breaker
  • Circuit Breaker Application
    HACR rated
  • Width
    2.94 in (74.68 mm)
  • Number Of Spaces Required
    3
  • Net Weight
    4 lb(US) (1.81 kg)
  • Maximum Operating Voltage
    480Y/277 V AC
  • Electrical Connection
    Lugs aluminium
  • Number Of Poles
    3
  • Line Rated Current
    80 A
  • Mounting Mode
    Bolt-on
  • Depth
    4.05 in (102.87 mm)
  • Device Short Name
    EGB
  • Holding Current
    1000 A
  • Range Of Product
    125 A Frame EDB-EGB-EJB
  • Number Of Spaces
    3
  • Breaking Capacity Code
    G
  • AWG Gauge
    AWG 12...AWG 2/0 aluminium AWG 14...AWG 2/0 copper
  • Protection Type
    Overload Short-circuit
  • Breaking Capacity
    35 kA 277 V AC 65 kA 240 V AC 35 kA 480Y/277 V AC 65 kA 120 V AC 65 kA 120/240 V AC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of EGB34080CA on Powermatic Associates is $1,550.00. Order now.

EGB34080CA Related Documents

Product Datasheet-1631035369114.pdfInstruction Sheet-1631035369124.pdfCatalog-1631035369110.pdf

Similar products from: Schneider Electric Electronic Components

QOB330GFI5237 on Powermatic Associates

QOB330GFI5237

Schneider Electric

Square D by Schneider Electric QOB330GFI5237 is a Ground Fault Interrupter (GFI) Miniature Circuit Breaker (MCB) designed for bolt-on mounting. It features a rated current of 30A and a bolt-on connection type. This MCB operates at a rated voltage of 208 V AC and accommodates a wire cross-section of 14-8AWG for one copper cable. It is a 3 Pole device with a residual current sensitivity of 6mA / 0.006. The QOB330GFI5237 offers ground fault protection and has a short circuit breaking rating of 10kA at both 120Vac and 208Vac. It is equipped with ring tongue type terminals.
